MAINTENANCE SERVICE
TSB Revision
GENERAL
00-79
22. REAR AXLE OIL (FOR DIFFERENTIAL PART)
(CHANGE)
M1001007200118
1. Remove the filler plug.
2. Remove the drain plug and drain oil.
3. Install the drain plug, and tighten it to the specified torque.
Tightening torque: 32
± 2 N⋅ m (23 ± 2 ft-lb)
4. Fill the specified gear oil up to the bottom of the filler plug
hole.
Specified gear oil: MITSUBISHI Genuine DIA QUEEN
Multi gear oil LS
Amount to use: 0.55
± 0.02 dm
3
(0.58
± 0.02 qt)
5. Install the filler plug, and tighten it to the specified torque.
Tightening torque: 49
± 10 N⋅ m (37 ± 7 ft-lb)
23. REAR AXLE OIL (FOR TORQUE TRANSFER
MECHANISM PART) (CHANGE)
M1001007500164
1. Remove the filler plug.
2. Remove the drain plug and drain oil.
3. Install the drain plug, and tighten it to the specified torque.
Tightening torque: 32
± 2 N⋅ m (23 ± 2 ft-lb)
4. Fill the specified gear oil up to the bottom of the filler plug
hole.
Specified gear oil: DIAMOND ATF-SP III
Amount to use: 0.55
− 0.60 dm
3
(0.58
− 0.63 qt)
5. Install the filler plug, and tighten it to the specified torque.
Tightening torque: 49
± 10 N⋅ m (37 ± 7 ft-lb)
24. TIRES (ROTATE)
M1001008900529
Rotate tires regularly to equalize tire wear and help extend tire
life. Recommended tire rotation is every 12,000 km (7,500
miles).
Timing for the rotation may vary according to vehicle condition,
road surface conditions, and individual driver's habits.
When rotating tires, check for uneven wear, damage, and
wheel alignment. Abnormal wear is usually caused by incorrect
tire pressure, improper wheel alignment, out-of balance
wheels, or severe braking.
The first rotation is the most important, to achieve more uniform
wear for all tires on the vehicle.
AC705198AC
Filler plug
Drain plug
AC705199AC
Filler plug
Drain plug
AC000120
