SEAT

TSB Revision

INTERIOR

52A-5

• Heated seats are adopted to the driver's and front

passenger's seats.<Vehicles with heated seat>

• Genuine leather and artificial leather seats are

provided. With the genuine leather and artificial
leather seat, the genuine leather is used to the
side section and the artificial leather is used to
the main section to enhance the texture, and the
double stitching is added to improve luxurious
feel. A separate material is added to the shoulder
and thigh sections to receive the lateral G during
cornering, ensuring the support function and
improving the functionality.<MR>

• Pads of seating surface, side section, and upper

back are separated to support the body with the
whole seatback, securing an excellent support
performance and further enhancing the balance
with usefulness.

SPECIFICATIONS FOR HEATED SEAT

REAR SEAT

M2520007000746

A low-back bench seat is used for rear seat. The rear
seat offer the following advantages:

• Soft leather and artificial leather are adopted for

enhanced luxurious feel.<MR>

• The center armrest has a cup holder.

• An upper tether anchor has been installed on the

rear shelf trim, and an ISO-FIX lower anchor has
been installed on the body side.

Item

Specification

ENERGY CONSUMPTION W

HIGH

61

± 6.1

LOW

16

± 1.6

THERMOSTAT

°C

ON

→ OFF

40

± 4

OFF

→ ON

30

± 5

AC708455

Cup holder

Head restraint
vertical adjustrment

AB

<Lower anchorage for child seat>

<Uper tether anchor>

SEAT BELT

TSB Revision

INTERIOR

52A-6

SEAT BELT

M2520010000898

FRONT SEAT BELT

• An ELR 3-point seat belt (driver's side) and

3-point seat belt with ELR/ALR changeover
mechanism (passenger's side) is used.

• One-touch push button style adjustable seat belt

anchor and retractable buckle provide the most
suitable belt fitting.

• The seat belt retractor with the force limiter for

the driver’s seat and the front passenger’s seat
increase safety.

• A seat belt warning light is installed to the driver’s

and passenger’s seat.

REAR SEAT BELT

• 3-point seat belt with ALR/ELR changeover

mechanism (LH/RH/Center) is used for the rear
seat.

AC708461

Seat belt warning lamp

Seat belt warning lamp

<USA>

<CANADA>

ELR 3-point seat belt

One-touch push button style
adjustable seat belt
shoulder anchor

ELR/ALR 3-point seat belt

Seat belt retractor
with a pre-tensioner
and force limiter

ELR/ALR 3-point seat belt

Seat belt
retractor

AB

ELR/ALR 3-point seat belt

ELR/ALR 3-point seat belt

SEAT BELT

TSB Revision

INTERIOR

52A-7

SEAT BELT RETRACTOR WITH FORCE LIMITER

.

The driver’s/front passenger’s seat belt retractor has been
equipped with a force limiter. The force limiter is a device which
operates when a predetermined force is applied, and limits the
force.

.

OPERATION

1. If a collision energy is transmitted to the seat belt, the ELR

mechanism will operate to lock the seat belt.

2. If the energy increases to a predetermined value, the torsion

bar will be distorted. As the spindle rotates together with the
torsion bar, the seat belt webbing is pulled out, reducing the
impact to the occupants.

AC100083

TORSION BAR

SPINDLE

BELT

AB

TRIMS

TSB Revision

INTERIOR

52A-8

TRIMS

INTERIOR TRIMS

M2520012000720

• The interiors are fully covered by trims.

• The energy absorption rib molding located in the

back side of the front pillar trim and the rear pillar
trim protect head from side impacts and the resin
materials for the trims are unbreakable materials.

• Use of nonflammable materials for the trims has

increased safety as outstanding interiors. Also,
material codes are indicated to deal with recy-
cling easily.

AC708640

Energy absorption rib

Front piller trim
(back side)

Front pillar trim

Cowl side trim

Center pillar trim upper

Rear piller trim

Front scuff plate

Center piller trim lower

Rear scuff plate

Trunk side trim

Rear end trim

Rear shelf trim

AB

Trunk lid trim

Trunk room trim front
