Functionality, interior comfort, and safety have been
emphasized, giving interior design for elegance and
relaxation space. Various measures have been taken
to protect the environment and recycle resources.

FEATURES

Quality improvement

1. Spartan, black monotone interior
2. Full interior trim

Usability improvement

1. Armrest (floor console, rear seat, front door trim

<MR>, rear door trim <MR>)

2. Cup holder (floor console, rear seat armrest)
3. Bottle holder (front door trim)

Convenient storage

1. Glove box
2. Card holder (glove box)
3. Tissue paper holder (floor console)
4. Floor console box
5. Door pocket (front door trim, rear door trim)

Safety improvement

1. Front and rear collision protection seat mecha-

nism (front seat)

2. ISO-FIX lower anchor (rear seat outside)
3. Upper tether anchor (rear shelf)
4. ELR 3-point seat belt (driver’s seat)
5. ELR/ALR 3-point seat belt (front passenger, rear)
6. Seat belt retractor with a driver's side preten-

sioner and force limiter

7. Seat belt retractor with a passenger’s side pre-

tensioner and force limiter

8. Headliner energy absorption rib <Vehicles with-

out curtain air bag>

Consideration for the optimum driving position

1. Seat slide adjustment (front)
2. Reclining adjustment (front)

Measures for resource recycling

1. Aggressively use PP materials that are easy to

recycle and easy to stamp material symbols on
the plastic (resin) parts.

2. Reduction of chemical material (formaldehyde

organic solvent)

NOTE:

: Clear and colourless, toxic, irritating odour

INSTRUMENT PANEL AND FLOOR CONSOLE

TSB Revision

INTERIOR

52A-3

INSTRUMENT PANEL AND FLOOR CONSOLE

M2520001000964

The instrument panel and the floor console have the
following features.

• The instrument panel is two-toned.

• The division unit of each part has been enlarged,

also the gap and level difference between the
instrument panel has been minimized to achieve
the delicate quality.

AC708443

Glove box

Card holder

Cup holder

Console box

Tray

Armrest

Center tray

Glove box

Ornament panel

SEAT

TSB Revision

INTERIOR

52A-4

• The decorated panel creating uniformity from the

instrument panel to the door trim has been
adopted.

• The holder in which two cards can be stored has

been installed in the glove box.

• The glove box with damper function has been

installed.

• The center tray for storing small items has been

installed in front of the selector or shift lever cen-
ter panel.

• The cup holder which can hold two 20-oz bottles

has been equipped. The cup holder can store two
CDs in the upright position and pen-size long
items horizontally.

• Under the arm rest a large box that can store 10

CDs has been equipped.

• A tray that can store cigarettes and lighters has

been equipped. <Vehicles without console
switch>

• The synthetic cloth is used for the arm rest lid to

enhance luxury and soft feelings.

SEAT

FRONT SEAT

M2520004001171

The front seats offer the following advantages.

• The seats are designed to be adjustable in the

reclining and sliding directions.

• The cross frame is established to the seat cush-

ion with frontal and rear-end collision protection
seat structure in order to restrain the forward
movement of passengers and minimize the
severity of an injury.

AC708449AB

Reclining adjustment

Sliding adjustment

Seat heater

Heated seat
switch

Cross frame
