Mitsubishi Evolution X. Manual - part 1256

CONTROLLER AREA NETWORK (CAN) <M/T>

TSB Revision

CIRCUIT DIAGRAMS

90-361

ASC-ECU

ENGINE
CONTROL
MODULE

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

CONTROLLER AREA NETWORK (CAN) <TC-SST>

TSB Revision

CIRCUIT DIAGRAMS

90-362

CONTROLLER AREA NETWORK (CAN) <TC-SST>

M1901004000602

ETACS-
ECU

FUSIBLE
LINK

34

DATA LINK
CONNECTOR

JOINT
CONNECTOR
(CAN1)

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

CAN
TRANSCEIVER
CIRCUIT

CPU

COMBINATION
METER

FRONT SIDE

OCCUPANT
CLASSIFICATION-
ECU

FRONT SEAT
ASSEMBLY (LH)

HEATED
SEAT

CONTROLLER AREA NETWORK (CAN) <TC-SST>

TSB Revision

CIRCUIT DIAGRAMS

90-363

CAN
TRANSCEIVER
CIRCUIT

CAN DRIVE
CIRCUIT

CAN DRIVE
CIRCUIT

KOS-ECU

INTERFACE
CIRCUIT

CAN BOX UNIT

HANDS FREE
MODULE

SRS-ECU

A/C-ECU

RADIO AND
CD PLAYER

SATELLITE
RADIO TUNER

NOTE

:
:

VEHICLES WITHOUT KOS
VEHICLES WITH KOS

: VEHICLES WITHOUT MMCS
: VEHICLES WITH MMCS

WIRELESS CONTROL
MODULE

CONTROLLER AREA NETWORK (CAN) <TC-SST>

TSB Revision

CIRCUIT DIAGRAMS

90-364

CONTROLLER AREA NETWORK (CAN) <TC-SST> (CONTINUED)

ETACS-
ECU

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

JOINT
CONNECTOR
(CAN2)

JOINT
CONNECTOR
(CAN3)

S-AWC-ECU

STEERING
WHEEL SENSOR
