HEATED SEAT

TSB Revision

CIRCUIT DIAGRAMS

90-317

HEATED
SEAT
ASSEMBLY
(RH)

THERMOSTAT

SEAT BACK
HEATER

THERMOSTAT

SEAT CUSHION
HEATER

HEATED SEAT
SWITCH

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

HEATER

HANDS FREE SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-318

HANDS FREE SYSTEM

M1901028600170

36

FUSIBLE
LINK

RELAY BOX

ENGINE
COMPARTMENT

MICROPHONE
UNIT

ETACS-
ECU

POWER
SUPPLY

HANDS
FREE
MODULE

·AUDIO SYSTEM
·MITSUBISHI
 MULTI-COMMUNICATION
 SYSTEM (MMCS)
·SPARE CONNECTOR
 (FOR NAVIGATION SYSTEM)

HANDS FREE SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-319

CAN DRIVE
CIRCUIT

INTERFACE CIRCUIT

ANALOG
INTERFACE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

ETACS-ECU

JOINT
CONNECTOR
(CAN3)

JOINT
CONNECTOR
(CAN2)

INPUT SIGNAL

·FRONT WHEEL
 SPEED SENSOR
·REAR WHEEL
 SPEED SENSOR

ASC-ECU

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

HANDS FREE SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-320

HANDS FREE SYSTEM (CONTINUED)

CLOCK
SPRING

STEERING
WHEEL
AUDIO
REMOTE
CONTROL
SWITCH

36

FUSIBLE
LINK

RELAY BOX

ENGINE
COMPARTMENT

ETACS-
ECU

<VEHICLES WITHOUT MITSUBISHI MULTI-COMMUNICATION SYSTEM (MMCS)>

COMBINATION
METER

CPU

RHEOSTAT

INTERFACE
CIRCUIT

INTERFACE
CIRCUIT

A/C
CONTROL
PANEL

NOTE

:

JOINT
CONNECTOR
(3)

·ABS, ASC, ACD,
 AYC AND S-AWC
·AUDIO SYSTEM
·HEADLIGHT LEVELING SYSTEM
·HEATED SEAT
·MITSUBISHI
 MULTI-COMMUNICATION
 SYSTEM (MMCS)

·ABS, ASC, ACD,
 AYC AND S-AWC
·HEADLIGHT
 LEVELING SYSTEM
·HEATED SEAT
