IMMOBILIZER SYSTEM <TC-SST>

TSB Revision

CIRCUIT DIAGRAMS

90-309

HEATED
SEAT

ENGINE
CONTROL
MODULE

FUSIBLE
LINK

34

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

JOINT
CONNECTOR
(CAN1)

DATA LINK
CONNECTOR

IMMOBILIZER SYSTEM <TC-SST>

TSB Revision

CIRCUIT DIAGRAMS

90-310

IMMOBILIZER SYSTEM <TC-SST> (CONTINUED)

·ABS, ASC, ACD, AYC AND S-AWC
·AIR CONDITIONING SYSTEM
·AUTO-CRUISE CONTROL SYSTEM
·BRAKE WARNING LIGHT,
 FUEL WARNING LIGHT AND
 OIL PRESSURE WARNING LIGHT
·CENTRAL DOOR LOCKING SYSTEM
·CHARGING SYSTEM
·COOLING SYSTEM
·DAYTIME RUNNING LIGHT (DRL)
·DOME LIGHT, LUGGAGE COMPARTMENT
 LIGHT AND IGNITION KEY HOLE
 ILLUMINATION LIGHT
·DOOR AJAR WARNING TONE ALARM
·FOG LIGHT
·HEADLIGHT
·HEATED SEAT
·IGNITION KEY REMINDER TONE ALARM
·METER AND GAUGE
·MFI SYSTEM
·PARKING BRAKE WARNING TONE ALARM
·REAR WINDOW DEFOGGER
·SEAT BELT WARNING TONE ALARM
·SUNROOF
·SUPPLEMENTAL RESTRAINT SYSTEM (SRS)
·TAILLIGHT, POSITION LIGHT,
 LICENSE PLATE LIGHT AND
 LIGHTING MONITOR TONE ALARM
·THEFT-ALARM SYSTEM
·TIRE PRESSURE MONITORING SYSTEM (TPMS)
·TRUNK LID OPENER
·TURN-SIGNAL LIGHT AND HAZARD WARNING LIGHT
·WINDSHIELD WIPER AND WASHER

34

FUSIBLE
LINK

IGNITION
SWITCH (IG1)

30

RELAY BOX
(FUSE      )

ETACS-
ECU

IMMOBILIZER
ANTENNA

ID
CODE

TRANSPONDER

<VEHICLES
 WITHOUT KOS>

JOINT CONNECTOR
(CAN1)

IG1
RELAY

WIRELESS CONTROL MODULE

:

NOTE

CAN DRIVE
CIRCUIT

IMMOBILIZER SYSTEM <TC-SST>

TSB Revision

CIRCUIT DIAGRAMS

90-311

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

·AIR CONDITIONING SYSTEM
·BRAKE WARNING LIGHT,
 FUEL WARNING LIGHT AND OIL
 PRESSURE WARNING LIGHT
·CENTRAL DOOR LOCKING SYSTEM
·DAYTIME RUNNING LIGHT (DRL)
·DOME LIGHT, LUGGAGE
 COMPARTMENT LIGHT AND
 IGNITION KEY HOLE
 ILLUMINATION LIGHT
·FOG LIGHT
·HEADLIGHT
·IGNITION KEY REMINDER TONE ALARM
 <VEHICLES WITH KOS>
·METER AND GAUGE
·SEAT BELT WARNING TONE ALARM
·TAILLIGHT, POSITION LIGHT,
 LICENSE PLATE LIGHT
 AND LIGHTING MONITOR
 TONE ALARM
·THEFT-ALARM SYSTEM
·TIRE PRESSURE MONITORING SYSTEM (TPMS)
·TRUNK LID OPENER
·TURN-SIGNAL LIGHT AND HAZARD WARNING LIGHT
·WINDSHIELD WIPER AND WASHER

IMMOBILIZER
ANTENNA

JOINT
CONNECTOR (6)

JOINT CONNECTOR
(CAN1)

ID
CODE

TRANSPONDER

RECEIVER ANTENNA MODULE

<VEHICLES WITH KOS>

KOS-ECU

CAN DRIVE
CIRCUIT

POWER
SUPPLY

:

KEYLESS
OPERATION
KEY

SUNROOF

TSB Revision

CIRCUIT DIAGRAMS

90-312

SUNROOF

M1901009902231

INTERFACE
CIRCUIT

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

LIN DRIVE
CIRCUIT

FUSIBLE
LINK

34

FRONT
DOOR
SWITCH
(LH)

ETACS-ECU

DATA LINK
CONNECTOR

FRONT SIDE

IGNITION
SWITCH (IG1)

IG1
RELAY

·ABS, ASC, ACD,
 AYC AND S-AWC
·AIR CONDITIONING SYSTEM
·AUTO-CRUISE
 CONTROL SYSTEM
·BRAKE WARNING LIGHT,
 FUEL WARNING LIGHT
 AND OIL PRESSURE
 WARNING LIGHT
·CENTRAL DOOR
 LOCKING SYSTEM
·CHARGING SYSTEM
·COOLING SYSTEM
·DAYTIME RUNNING LIGHT (DRL)
·DOME LIGHT, LUGGAGE
 COMPARTMENT LIGHT
 AND IGNITION KEY HOLE
 ILLUMINATION LIGHT
·DOOR AJAR WARNING
 TONE ALARM
·FOG LIGHT
·HEADLIGHT
·HEATED SEAT
·IGNITION KEY REMINDER
 TONE ALARM

HEATED
SEAT

NOTE

:

·IMMOBILIZER SYSTEM
·KEYLESS OPERATING SYSTEM
 (KOS)
·METER AND GAUGE
·MFI SYSTEM
·PARKING BRAKE WARNING
 TONE ALARM
·REAR WINDOW DEFOGGER
·SEAT BELT WARNING TONE ALARM
·SHIFT LOCK MECHANISM
·SUPPLEMENTAL RESTRAINT
 SYSTEM (SRS)
·TAILLIGHT, POSITION LIGHT,
 LICENSE PLATE LIGHT AND
 LIGHTING MONITOR TONE ALARM
·TC-SST
·THEFT-ALARM SYSTEM
·TIRE PRESSURE MONITORING
 SYSTEM (TPMS)
·TRUNK LID OPENER
·TURN-SIGNAL LIGHT AND
 HAZARD WARNING LIGHT
·WINDSHIELD WIPER AND WASHER

·HEADLIGHT
·TAILLIGHT, POSITION
 LIGHT, LICENSE PLATE
 LIGHT AND LIGHTING
 MONITOR TONE ALARM
·WINDSHIELD
 WIPER AND WASHER
