Mitsubishi Evolution X. Manual - part 1236
AUTO-CRUISE CONTROL SYSTEM <M/T>
TSB Revision
CIRCUIT DIAGRAMS
90-281
CAN DRIVE
CIRCUIT
INTERFACE
CIRCUIT
COMBINATION
METER
JOINT
CONNECTOR
(CAN1)
(FUSE )
12
ETACS-ECU
CPU
CAN
TRANSCEIVER
CIRCUIT
LED DRIVE
CIRCUIT
ASC-ECU
WIRE COLOR CODE
B : BLACK LG : LIGHT GREEN G : GREEN L : BLUE W : WHITE Y : YELLOW SB : SKY BLUE
BR : BROWN O : ORANGE GR : GRAY R : RED P : PINK V : VIOLET PU : PURPLE SI : SILVER
INPUT SIGNAL
·FRONT WHEEL
SPEED SENSOR
·REAR WHEEL
SPEED SENSOR
·ABS, ASC, ACD,
AYC AND S-AWC
·AIR CONDITIONING SYSTEM
·CENTRAL DOOR
LOCKING SYSTEM
·DAYTIME RUNNING LIGHT (DRL)
·DOME LIGHT, LUGGAGE
COMPARTMENT LIGHT
AND IGNITION KEY HOLE
ILLUMINATION LIGHT
·FOG LIGHT
·HEADLIGHT
·HEATED SEAT
·IGNITION KEY REMINDE
TONE ALARM
·IMMOBILIZER SYSTEM
·KEYLESS OPERATING
SYSTEM (KOS)
·REAR WINDOW DEFOGGER
·SEAT BELT WARNING
TONE ALARM
·SUNROOF
·SUPPLEMENTAL RESTRAINT
SYSTEM (SRS)
·TAILLIGHT, POSITION LIGHT,
LICENSE PLATE LIGHT AND
LIGHTING MONITOR
TONE ALARM
·THEFT-ALARM SYSTEM
·TIRE PRESSURE MONITORING
SYSTEM (TPMS)
·TRUNK LID OPENER
·TURN-SIGNAL LIGHT AND
HAZARD WARNING LIGHT
·WINDSHIELD
WIPER AND WASHER
