SUPPLEMENTAL RESTRAINT SYSTEM (SRS)

TSB Revision

CIRCUIT DIAGRAMS

90-273

WEIGHT
SENSOR
(FRONT: LH)

WEIGHT
SENSOR
(REAR: LH)

WEIGHT
SENSOR
(REAR: RH)

WEIGHT
SENSOR
(FRONT: RH)

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE
Y : YELLOW     SB : SKY BLUE     BR :BROWN     O : ORANGE     GR : GRAY
R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

SUPPLEMENTAL RESTRAINT SYSTEM (SRS)

TSB Revision

CIRCUIT DIAGRAMS

90-274

SUPPLEMENTAL RESTRAINT SYSTEM  (SRS) (CONTINUED)

PASSENGER'S
SIDE

CENTER
PANEL
UNIT

ETACS-ECU

(FUSE     )

12

INTERFACE
CIRCUIT

SRS-
ECU

AIR BAG OFF
INDICATOR
LIGHT
PASSENGER'S
SIDE

HALL IC

SEAT BELT
SWITCH

SEAT BELT WARNING
TONE ALARM

SUPPLEMENTAL RESTRAINT SYSTEM (SRS)

TSB Revision

CIRCUIT DIAGRAMS

90-275

NOTES

AUTO-CRUISE CONTROL SYSTEM <M/T>

TSB Revision

CIRCUIT DIAGRAMS

90-276

AUTO-CRUISE CONTROL SYSTEM <M/T>

M1901009302756

MFI SYSTEM

36

FUSIBLE
LINK

RELAY BOX

ENGINE
COMPARTMENT

MFI
RELAY

ENGINE CONTROL MODULE

BATTERY
BACKUP

THROTTLE VALVE
DRIVE POWER
SUPPLY

POWER
SUPPLY

THROTTLE
ACTUATOR
CONTROL
MOTOR
RELAY
