ABS, ASC, ACD, AYC AND S-AWC <TC-SST>

TSB Revision

CIRCUIT DIAGRAMS

90-265

NOTES

SUPPLEMENTAL RESTRAINT SYSTEM (SRS)

TSB Revision

CIRCUIT DIAGRAMS

90-266

SUPPLEMENTAL RESTRAINT SYSTEM (SRS)

M1901009702497

ACCELERO
METER

CPU

(LH)

(RH)

FRONT
IMPACT
SENSOR

SRS-ECU

CLOCK
SPRING

DRIVER'S
AIR BAG
MODULE
(SQUIB)

CONNECTOR
LOCK
SWITCH

SUPPLEMENTAL RESTRAINT SYSTEM (SRS)

TSB Revision

CIRCUIT DIAGRAMS

90-267

KNEE AIR BAG
MODULE (SQUIB)

SEAT BELT
PRE-TENSIONER (RH)

PASSENGER'S
(FRONT)
AIR BAG MODULE
(SQUIB)

NOTE

: CONNECTOR COUPLED: ON

CONNECTOR UNCOUPLED: OFF

CONNECTOR
LOCK
SWITCH

SEAT BELT
PRE-TENSIONER (LH)

WIRE COLOR CODE
B : BLACK LG : LIGHT GREEN G : GREEN L : BLUE W : WHITE Y : YELLOW SB : SKY BLUE
BR : BROWN O : ORANGE GR : GRAY R : RED P : PINK V : VIOLET PU : PURPLE SI : SILVER

SUPPLEMENTAL RESTRAINT SYSTEM (SRS)

TSB Revision

CIRCUIT DIAGRAMS

90-268

SUPPLEMENTAL RESTRAINT SYSTEM (SRS) (CONTINUED)

SIDE IMPACT SENSOR
(LH)

ACCELERO
METER

CPU

SIDE-AIR BAG MODULE
(SQUIB) (LH)

CURTAIN AIR BAG MODULE
(SQUIB) (LH)

CONNECTOR
LOCK
SWITCH
