Mitsubishi Evolution X. Manual - part 1206

POWER WINDOWS

TSB Revision

CIRCUIT DIAGRAMS

90-161

FRONT
POWER
WINDOW
SUB
SWITCH

FRONT
POWER
WINDOW
MOTOR (RH)

POWER WINDOW
RELAY

POWER WINDOW
MAIN SWITCH

ETACS-ECU

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

CENTRAL DOOR LOCKING SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-162

CENTRAL DOOR LOCKING SYSTEM

M1901004705220

ETACS-ECU

FUSIBLE
LINK

37

DOOR
LOCK
RELAY

FRONT SIDE

DRIVER'S
DOOR
UNLOCK
RELAY

PASSENGER'S
DOOR
UNLOCK
RELAY

DOME LIGHT, LUGGAGE
COMPARTMENT LIGHT
AND IGNITION KEY HOLE
ILLUMINATION LIGHT

REAR
WINDOW
DEFOGGER

CENTRAL DOOR LOCKING SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-163

HEATED
SEAT

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

FUSIBLE
LINK

34

TURN-SIGNAL
LIGHT CONTROL
CIRCUIT

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

DATA LINK
CONNECTOR

TURN-SIGNAL LIGHT AND
 HAZARD WARNING LIGHT

CENTRAL DOOR LOCKING SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-164

CENTRAL DOOR LOCKING SYSTEM (CONTINUED)

DOOR
LOCK
RELAY

DRIVER'S
DOOR
UNLOCK
RELAY

PASSENGER'S
DOOR UNLOCK
RELAY

ETACS-ECU

FRONT
DOOR
LOCK
ACTUATOR
(RH)

FRONT
DOOR
LOCK
ACTUATOR
(LH)

VEHICLES
WITH KOS

JOINT
CONNECTOR
(3)

JOINT
CONNECTOR
(3)
