HEADLIGHT <DISCHARGE TYPE>
TSB Revision
CIRCUIT DIAGRAMS
90-97
(HEAD)
(TAIL)
(AUTO)
COLUMN SWITCH
JOINT
CONNECTOR
(2)
COLUMN-ECU
LIGHTING
SWITCH
DIMMER
SWITCH
(DIMMER)
(PASSING)
PASSING
SWITCH
WIRE COLOR CODE
B : BLACK LG : LIGHT GREEN G : GREEN L : BLUE W : WHITE Y : YELLOW SB : SKY BLUE
BR : BROWN O : ORANGE GR : GRAY R : RED P : PINK V : VIOLET PU : PURPLE SI : SILVER
12
(FUSE )
ETACS-ECU
ETACS-ECU
(FUSE )
8
ETACS-ECU
LIN DRIVE
CIRCUIT
·ABS, ASC, ACD,
AYC AND S-AWC
·AIR CONDITIONING
SYSTEM
·CENTRAL DOOR
LOCKING SYSTEM
·DOME LIGHT,
LUGGAGE
COMPARTMENT
LIGHT AND
IGNITION KEY HOLE
ILLUMINATION LIGHT
·HEATED SEAT
·IGNITION KEY
REMINDER
TONE ALARM
·IMMOBILIZER SYSTEM
·KEYLESS OPERATING
SYSTEM (KOS)
·REAR WINDOW
DEFOGGER
·SEAT BELT WARNING
TONE ALARM
·SHIFT LOCK
MECHANISM
·SUNROOF
·SUPPLEMENTAL
RESTRAINT
SYSTEM (SRS)
·TC-SST
·THEFT-ALARM
SYSTEM
·TIRE PRESSURE
MONITORING
SYSTEM (TPMS)
·TRUNK LID OPENER
·AIR CONDITIONING
SYSTEM
·BRAKE WARNING LIGHT,
FUEL WARNING LIGHT
AND OIL PRESSURE
WARNING LIGHT
·CENTRAL DOOR
LOCKING SYSTEM
·DOME LIGHT,
LUGGAGE COMPARTMENT
LIGHT AND IGNITION KEY
HOLE ILLUMINATION LIGHT
·FOG LIGHT
·HEADLIGHT
·IGNITION KEY REMINDER
TONE ALARM
<VEHICLES WITH KOS>
·IMMOBILIZER SYSTEM
·KEYLESS OPERATION
SYSTEM (KOS)
·METER AND GAUGE
·SEAT BELT WARNING
TONE ALARM
·THEFT-ALARM SYSTEM
·TIRE PRESSURE
MONITORING SYSTEM
(TPMS)
·TRUNK LID OPENER
