HEADLIGHT <HALOGEN TYPE>

TSB Revision

CIRCUIT DIAGRAMS

90-93

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

CPU

INTERFACE
CIRCUIT

CAN DRIVE
CIRCUIT

JOINT
CONNECTOR
(CAN1)

COMBINATION
METER

CAN
TRANSCEIVER
CIRCUIT

LED DRIVE
CIRCUIT

12

(FUSE     )

ETACS-ECU

HEADLIGHT <HALOGEN TYPE>

TSB Revision

CIRCUIT DIAGRAMS

90-94

HEADLIGHT <HALOGEN TYPE> (CONTINUED)

ETACS-ECU

FRONT
DOOR
SWITCH
(LH)

IGNITION
SWITCH (ACC)

(FUSE     )

8

ETACS-ECU

LIGHTING
CONTROL
SENSOR

SUNROOF

<VEHICLES WITH AUTOMATIC LIGHT>

HEADLIGHT <HALOGEN TYPE>

TSB Revision

CIRCUIT DIAGRAMS

90-95

RELAY BOX

ENGINE
COMPARTMENT

FUSIBLE
LINK

36

IGNITION
SWITCH (IG1)

FUSIBLE
LINK

34

IG1
RELAY

HEADLIGHT
RELAY (LOW)

HEADLIGHT
RELAY (HIGH)

INTERFACE
CIRCUIT

LIN DRIVE
CIRCUIT

HEADLIGHT
BACKUP CIRCUIT

IGNITION
CONTROL
CIRCUIT

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

HEATED
SEAT

HEADLIGHT <DISCHARGE TYPE>

TSB Revision

CIRCUIT DIAGRAMS

90-96

HEADLIGHT <DISCHARGE TYPE>

M1901001503834

FUSIBLE
LINK

36

DISCHARGE-ECU

DISCHARGE-ECU

HEADLIGHT
ASSEMBLY
(RH)

SOLENOID

SOLENOID

HEADLIGHT
ASSEMBLY
(LH)

HEADLIGHT
RELAY (LOW)

HEADLIGHT
RELAY (HIGH)

RELAY BOX
 ENGINE
 COMPARTMENT

NOTE

: VEHICLES WITH

AUTOMATIC LIGHT
