CENTRALIZED JUNCTION

TSB Revision

CIRCUIT DIAGRAMS

90-21

20

MFI relay

Fuse

−

−

−

21

10

Red

Ignition coil Nos.1 to 4

22

20

Yellow

Engine control module, evaporative
emission purge solenoid, exhaust oil
feeder control valve, heated oxygen
sensor (Front, rear), injector Nos.1 to
4, intake oil feeder control valve,
mass airflow sensor, throttle actuator
control motor relay and turbocharger
wastegate solenoid No.1 and 2

23

20

Yellow

Fuel pump module, fuel pump relay 1
and fuel pump circuit resistor

24

Fusible link No.36

Fusible
link

30

Pink

Starter

25

−

−

−

26

40

Green

ASC-ECU

27

30

Pink

ASC-ECU

28

30

Pink

Condenser fan motor, condenser fan
relay and fan control relay

29

40

Green

Radiator fan motor and radiator fan
relay

30

Fuse

30

Green

Fuse Nos.7 to 9 in passenger
compartment

31

30

Green

Audio amplifier

32

MFI relay

−

−

−

33

Battery/Generator

Fusible
link

140

−

Fusible link No.37/ Fusible link No.34
to 36

34

Battery/Fusible link
No.33

80

−

ACC relay 3 in ETACS-ECU, fuse
No.2, 4, 5, 10, 11, 12, 14, 15, 17, 18,
25 and fusible link No.20 in
passenger compartment and
ETACS-ECU

35

80

−

Electric pump

36

120

−

Fuse No.1 to 5, 7 to 9, 13 to 23, 30,
31 and fusible link No.24, 26 to 29 in
engine compartment, MFI relay and
headlight relay (High, Low)

37

Fusible link No.33/
Generator

80

−

ACC relay 2 in ETACS-ECU, fusible
link No.1 and 21, Fuse No. 3, 6, 13,
16 in passenger compartment,
ETACS-ECU and blower relay

No. Power supply circuit Name

Rated
capacity (A)

Housing
color

Load circuit

CENTRALIZED JUNCTION

TSB Revision

CIRCUIT DIAGRAMS

90-22

.

AC609168

3

2

1

16 17

31 32

18 19

20 21

23

22

5

25

4

6

7

8

9

10

11

12

13

14

15

24

AT

27

26

29

28

30

Front of
vehicle

Relay box in engine compartment

AC506810AJ

33

35

36

37

34

Front of
vehicle

Fusible link box in engine compartment

CENTRALIZED JUNCTION

TSB Revision

CIRCUIT DIAGRAMS

90-23

PASSENGER COMPARTMENT

No. Power supply circuit Name

Rated
capacity (A)

Housing
color

Load circuit

1

Fusible link No.37

Fusible
link

30

Pink

Blower motor

2

Fusible link No.34

Fuse

15

Blue

ETACS-ECU, high-mounted stoplight,
rear combination light (LH, RH) and
shift lever <TC-SST>

3

Fusible link No.37

10

Red

−

4

ETACS-ECU (ACC
relay 3)

30

Green

Windshield wiper automatic stop
relay, windshield wiper motor and
windshield wiper speed switching
relay in ETACS-ECU, washer motor
and windshield washer relay

5

Fusible link No.34

10

Red

Data link connector

6

Fusible link No.37

20

Yellow

Door lock relay, driver's door unlock
relay, passenger's door unlock relay
and trunk lid open relay in
ETACS-ECU, front door lock actuator
(LH, RH), rear door lock actuator (LH,
RH) and trunk lid latch

7

Fusible link No.30

15

Blue

CAN box unit, center panel unit,
hands free module, multivision
display, radio/CD player, satellite
radio tuner and spare connector (for
navigation unit)

8

7.5

Brown

Power window relay in ETACS-ECU,
A/C-ECU, column switch,
combination meter, ETACS-ECU, key
reminder switch <Vehicles with
KOS>, KOS-ECU, lighting control
sensor, S-AWC-ECU and wireless
control module

9

15

Blue

Center panel unit, combination meter
and key reminder switch <Vehicles
without KOS>

10

Fusible link No.34

15

Blue

ETACS-ECU

11

ETACS-ECU (ACC
relay 3)

15

Blue

−

CENTRALIZED JUNCTION

TSB Revision

CIRCUIT DIAGRAMS

90-24

12

ETACS-ECU (IG1
relay)

7.5

Brown

A/C-ECU, A/C control panel, center
panel unit, column switch,
combination meter, heated seat relay,
KOS-ECU, rear window defogger
relay, receiver antenna module
<Vehicles with KOS>, S-AWC-ECU,
shift lever <TC-SST>, SRS-ECU,
steering wheel sensor, sunroof motor
assembly, transaxle assembly
<TC-SST> and wireless control
module <Vehicles without KOS>

13

ETACS-ECU (ACC
relay 2)

15

Blue

Accessory socket and cigarette lighter

14

Fusible link No.34

10

Red

Fuel pump relay 2, IG1 relay, power
window relay in ETACS-ECU,
ETACS-ECU, engine control module
and injector relay

15

20

Yellow

Sunroof motor assembly

16

ETACS-ECU (ACC
relay 2)

10

Red

CAN box unit, multivision display,
radio/CD player, door mirror assembly
(LH, RH) and shift lever <TC-SST>

17

Fusible link No.34

10

Red

ASC-ECU, front seat assembly (LH)
and S-AWC-ECU

18

ETACS-ECU (IG1
relay)

7.5

Brown

Backup light (LH, RH), ETACS-ECU,
multivision display, shift lever
<TC-SST>, spare connector (for
navigation unit) and SRS-ECU

19

Fusible link No.37

15

Blue

−

20

Fusible link No.34

Fusible
link

30

Pink

Front power window sub switch,
power window main switch and rear
power window motor (LH, RH)

21

Fusible link No.37

30

Pink

Rear window defogger

22

−

Fuse

−

−

−

23

Fusible link No.34

−

−

−

24

−

−

−

25

30

Green

Heated seat assembly (LH, RH) and
heated seat switch

No. Power supply circuit Name

Rated
capacity (A)

Housing
color

Load circuit
