WATER PASSAGE
TSB Revision
ENGINE COOLING
14-3
WATER PASSAGE
M2140004000398
WATER PUMP
M2140003000317
The water pump is the centrifugal, impeller type that
is installed in front of the cylinder block. It is driven by
the drive belt.
AK703252AC
Heater
Water pipe
Water pump
Cylinder block
Cylinder head
Radiator
Throttle body
Thermostat
housing
Turbocharger
AK503034
Impeller
AD
Item
Specifications
Discharge volume L/min
dm
3
(qt)
185 (195)
Impeller diameter mm (in)
62 (2.4)
Pulley outer diameter mm
(in)
137 (5.4)
