DIAGNOSIS TSB Revision CONTROLLER AREA NETWORK (CAN) 54C-119 . FUNCTION If a failure is present in the wiring harness between . TROUBLE JUDGEMENT CONDITIONS If a communication flag is not set for some of the . TROUBLESHOOTING HINTS • Malfunction of the connector [joint connector (CAN2), joint connector (CAN3) or intermediate • Malfunction of the wiring harness [open circuit between joint connector (CAN2) and joint con- DIAGNOSIS Required Special Tools: • MB991223: Harness Set • MB992006: Extra Fine Probe STEP 1. Check joint connector (CAN2) C-104, joint CAUTION The strand end of the twisted wire should be within 10 cm Q: Are joint connector (CAN2) C-104, joint connector (CAN3) C-127 and intermediate connector C-131 in good AC708950BY C-104 C-131 Connectors: C-104, C-131 AC708951CC Connector: C-127 |
