PANIC ALARM SYSTEM

TSB Revision

CHASSIS ELECTRICAL

54A-47

CONSTRUCTION DIAGRAM

CUSTOMIZATION FUNCTION

By operating the ETACS system or MMCS of scan
tool MB991958, the following functions can be pro-
grammed. The programmed information is held even
when the battery is disconnected.

AC709446

PANIC

Panic button

Theft-alarm horn

Horn (HIGH)

Horn (LOW)

Headlight

ETACS-ECU

Adjustment item (scan
tool MB991958 display)

Adjustment item

Adjusting contents
(scan tool MB991958
display)

Adjusting content

Panic alarm switch

With/without panic alarm
function

Disable

Without function

Enable

With function (default)

REAR WINDOW DEFOGGER

TSB Revision

CHASSIS ELECTRICAL

54A-48

REAR WINDOW DEFOGGER

GENERAL INFORMATION

M2546600100023

The rear window defogger has been established to
the rear window glass. To prevent battery discharge,
A/C-ECU controls the rear window defogger to be
automatically turned off 20 minutes after the rear
window defogger switch is turned ON. (Only when
engine is running)

AC608069

AC608068

AC708613

<Vehicles for USA>

Rear window defogger switch

<Vehicles for CANADA>

Rear window
defogger switch
