TECHNICAL FEATURES

TSB Revision

GENERAL

00-22

.

The electric sliding glass sunroof with tilt-up mecha-
nism has been adopted as an option. This sunroof
has the following characteristics:

• A lightweight sunroof has been adopted.

• The sunroof tilts up for approximately 30 mm (1.2

inches) to improve ventilation.

• The integrated switch for the sunroof allows for all

slide open/close, tilt up/down and stop opera-
tions. Operations other than open are available at
one touch. When the open switch is operated, the
sunroof lid glass stops approximately 30 mm (1.2
inches) before the fully-open position. This posi-
tion is called comfort position. The sunroof lid
glass can be fully opened by operating the open
switch again.

• If external force is applied during slide closing or

tilt down operations that obstructs operations, the
sunroof lid glass will move in the reverse direc-
tion.

• By turning ON the sunroof window lock switch

(integrated in the power window main switches)
of the driver's power window switch, the sunroof
operation is prevented.

AC505239

AC505240

AC506511AC

Sunroof switch

Open switch

Close/down switch

Tilt-up switch

TECHNICAL FEATURES

TSB Revision

GENERAL

00-23

RAIN SENSITIVE AUTOMATIC WINDSHIELD WIPER FUNCTION <OPTIONAL:
VEHICLES FOR USA WITH LIGHTING CONTROL SENSOR (RAIN SENSOR) >

.

Lighting control sensor (rain sensor) has been
installed on the upper part of the windshield to sense
the raindrops and windshield wiper can be operated
automatically when the ignition switch is at ON and
wiper switch at AUTO position.

• The amount of rainfall on the windshield surface

are detected by using the infrared reflection, and
intermittent operation or LO and HI operation of
the windshield wiper is controlled automatically
depending on the amount of rainfall.

• Dry windshield: All infrared rays emitted from the

emitter diode are reflected by the windshield and
directed to the receiver diode as they are.

• Wet windshield: Part of the infrared rays emitted

from the emitter diode are transmitted to outside
of the windshield through the raindrops, and the
infrared rays with reduced intensity are directed
to the receiver diode.

NOTE: Using the configuration function, the rain sen-
sitive automatic windshield wiper function can be
invalidated (Refer to

P.51-12

).

MITSUBISHI MULTI COMMUNICATION SYSYEM

• For Mitsubishi multi-communication system

(MMCS), the multivision display (7-inch liquid
crystal display of wide 2 DIN size) with hard disk
drive (30 GB) and the CD/DVD drive is estab-
lished.

• Rockford Fosgate Premium Sound System

(9-speaker, 7-position system) is supported.

AC708778AB

Windshield

Lighting control sensor (rain sensor)

Windshield

Receiver diode

Emitter diode

Raindrop

High
intensity

Receiver diode

Emitter diode

Reduced
intensity

Windshield

Optical
element

Optical
element

Dry windshield

Wet windshield

Infrared rays

Infrared rays

AC608322AD

Multivision display

TECHNICAL FEATURES

TSB Revision

GENERAL

00-24

HANDS FREE CELLULAR PHONE SYSTEM

.

With the hands free cellular phone system by regis-
tering a cellular phone for Bluetooth

™

*

 with voice rec-

ognition to the hands free module, the telephone
function becomes available without operating the cel-
lular phone directly. The hands free cellular phone
system can be used without connecting the cellular
phone to the vehicle via wiring cable.

NOTE:

*

: Bluetooth

™

 is the short-distance digital

wireless communication technology using 2.45 GHz
frequency band. The communication effective area is
within 10 m, and the feature is that the communica-
tion can be achieved even when an obstacle is
present between the communicating devices.

STEERING WHEEL REMOTE CONTROL SWITCH

.

On the steering wheel spoke, the steering wheel
audio remote control switch and steering wheel voice
control switch have been established.

.

STEERING WHEEL AUDIO REMOTE
CONTROL SWITCH

With the steering wheel audio remote control switch,
the sound volume adjustment, mode changeover,
CD track up/down and other operation of multivision
display, radio, and CD player are available.

.

STEERING WHEEL VOICE CONTROL
SWITCH

With the steering wheel voice control switch, the
hands free cellular phone system can be oper-
ated.(Refer to

P.54A-33

.)

AC700417



Microphone unit
(built in front dome light)

“Speech”
 switch

“Pick-up”
 switch

“Hang-up”
 switch



Steering wheel
voice control
switch



Hands free module

AE

AC705510AB

MODE

<Steering wheel audio remote control switch>

“VOL up” switch

“CH up”
switch

“CH down”
switch

“Mode” switch

“VOL down”
switch

“Speech”
 switch

“Pick-up”
 switch

“Hang-up”
 switch

<Steering wheel voice control switch>



TECHNICAL FEATURES

TSB Revision

GENERAL

00-25

ROCKFORD FOSGATE

® PREMIUM

SOUND SYSTEM

.

AUDIO AMPLIFIER

The 8-ch high-power audio amplifier with integrated
DSP (total maximum output of 650 W) equipped with
the front seat (left side) has been combined with the
9-speaker 7-position system, adopting the Rockford
Fosgate

® premium sound system. The audio ampli-

fier offers the clear treble without distortion.

.

SUBWOOFER

To the trunk room, a 25-cm dual voice coil subwoofer
and a 20-liter subwoofer sealed box are installed.
The punched sound with dynamic deep bass and
rhythm can be played back.

AUDIO AND VIDEO ADAPTER <VEHICLE WITH MMCS>

The audio and video adapter has been established to
the center tray in order to connect visual equipment
such as game machine and video player.

ACCESSORY SOCKET

The plug-in type accessory socket has been installed
for the convenient use of accessories. This acces-
sory socket can be replaced to the cigar lighter as an
option.
Accessory socket has been added to the front floor
console. The maximum load is 120 W when a single
accessory socket is used

AC608321AD

Front seat
(left side)

Audio amplifier

Rear seat

AC608344AB

Subwoofer

Trunk room

AC608418AB

Audio and video adapter

AC706142AB

Accessory socket
