Mitsubishi Evolution X. Manual - part 42





REAR FLOOR

TSB Revision

WELDED PANEL REPLACEMENT

3-38

NOTE ON REPAIR WORK

.

REMOVAL

When removing the rear floor side panel, cut it 290 mm (11.4
inches) behind the installation hole of the child restraint
bracket.

AB700940

C

B

AB

E

D

AB700599

AB

290 mm

(11.4 in)

(With the rear floor rear removed)

QUARTER INNER

TSB Revision

WELDED PANEL REPLACEMENT

3-39

QUARTER INNER

M4030012001093

CAUTION

When repairing the area using sound dampening foam material do not use firing tools since the
sound dampening foam material may burn.
NOTE: Refer to the Quarter Outer section on

P.3-29

 for the welding points with the quarter outer.

AB700430

Spot welding

MIG plug welding

: indicates two panels to be welded

: indicates three panels to be welded

MIG spot welding

MIG arc welding (continuous)

Braze welding

Anti-corrosion agent application locations
(Use access holes to apply liberally to butt-welded joints.)

(                                                               )

Symbol

Operation description

AB

AB700999

A

AB

A

F

B

G

B

REPAIR WELDS

(With the quarter outer removed)

Left side
only

Sound
dampening
foam material

Sound dampening
foam material

Sound dampening
foam material

Sound dampening
foam material

QUARTER INNER

TSB Revision

WELDED PANEL REPLACEMENT

3-40

AB701000AB

E

C

D

Right side

C

E

D

Right side only

Right side only

Right side only

Right side only

Right side only

Right side only

Right side

Right side

Right side

(With the rear pillar reinforcement and the rear pillar reinforcement lower removed)

QUARTER INNER

TSB Revision

WELDED PANEL REPLACEMENT

3-41

AB700546 AB

G

F

H

F

(Left side)

(Right side)

H

(With the rear wheel house
panel front lower outer removed)
