Mitsubishi Lancer Evolution X. Manual - part 88





AIR CLEANER

TSB Revision

INTAKE AND EXHAUST

15-11

AIR CLEANER

REMOVAL AND INSTALLATION

M1151002101951

AC710665

2

1

5

13

14

15

7

12

11

17

AB

10

3

4

6

8

16

9.5 ± 3.5 N·m
84 ± 31 in-lb

9.5 ± 3.5 N·m
84 ± 31 in-lb

7.0 ± 3.0 N·m
62 ± 27 in-lb

4.0 ± 1.0 N·m
36 ± 8 in-lb

4.0 ± 1.0 N·m
36 ± 8 in-lb

1.5 ± 0.3 N·m
14 ± 2 in-lb

6.0 ± 1.0 N·m
53 ± 9 in-lb

8.5 ± 2.5 N·m
75 ± 22 in-lb

8.5 ± 2.5 N·m
75 ± 22 in-lb

9

N

Removal steps

1.

Air cleaner intake duct

2.

Air cleaner element

3.

Air cleaner body

4.

Air by-pass valve vacuum hose
connection

5.

Air by-pass valve connection

6.

Harness clamp connection

7.

Mass airflow sensor connector
connection

8.

Air cleaner cover assembly

>>

A

<<

9.

Mass airflow sensor

10. Air cleaner support
11. Gasket
12. Air cleaner cover
13. Breather hose connection
14. Vacuum hose connection
15. Air cleaner intake hose
16. Harness clamp connection
17. Air cleaner bracket

Removal steps (Continued)

CHARGE AIR COOLER

TSB Revision

INTAKE AND EXHAUST

15-12

INSTALLATION SERVICE POINT

.

>>A<< MASS AIRFLOW SENSOR INSTALLATION

CAUTION

Do not over-tighten. If the mass airflow sensor installation
screw is over-tightened, the air cleaner support thread
may be damaged.

CHARGE AIR COOLER

REMOVAL AND INSTALLATION

M1151002401026

CAUTION

• Degrease the air hose and air pipe by isopropyl alcohol, parts cleaner (MZ100387) or equivalent.
• As for the parts cleaner, use the petroleum cleaner whose major component is aliphatic hydrocar-

bon.

• Working area should be airy and kept from flame.

AC709089

1

AB

2

3

4

5

6

7

8

9

10

11

14

12

13

13

6.0 ± 1.0 N·m
54 ± 8 in-lb

20 ± 5 N·m
15 ± 3 ft-lb

9.5 ± 3.5 N·m
85 ± 30 in-lb

6.0 ± 1.0 N·m
54 ± 8 in-lb

6.0 ± 1.0 N·m
54 ± 8 in-lb

6.0 ± 1.0 N·m
54 ± 8 in-lb

6.0 ± 1.0 N·m
54 ± 8 in-lb

9.5 ± 3.5 N·m
85 ± 30 in-lb

6.0 ± 1.0 N·m
54 ± 8 in-lb

9.5 ± 3.5 N·m
85 ± 30 in-lb

6.0 ± 1.0 N·m
54 ± 8 in-lb

6.0 ± 1.0 N·m
54 ± 8 in-lb

6.0 ± 1.0 N·m
54 ± 8 in-lb

9.5 ± 3.5 N·m
85 ± 30 in-lb

Removal steps

1.

Turbocharger by-pass valve
vacuum hose connection

2.

Turbocharger by-pass valve

<<A>>

>>A<<

3.

Charge air cooler intake hose A

4.

Charge air cooler intake pipe A

<<A>>

>>A<<

5.

Charge air cooler intake hose B

Removal steps (Continued)

CHARGE AIR COOLER

TSB Revision

INTAKE AND EXHAUST

15-13

REMOVAL SERVICE POINT

.

<<A>> AIR HOSE/AIR PIPE REMOVAL

Put mating marks on the air hose, air pipe, and hose clamp,
and remove them.

INSTALLATION SERVICE POINT

.

>>A<< AIR HOSE/AIR PIPE INSTALLATION

1. Insert hose to stopper end and not overlap with stopper.
2. Place the hose clamp as shown in the figure so that it does

not overlap with the bulge and the stopper end. Then, set
the hose clamp 5 ± 1 mm (0.20 ± 0.04 inch) away from the

stopper.

Air cleaner body (Refer to

P.15-11

)

<<A>>

>>A<<

6.

Turbocharger by-pass valve hose

<<A>>

>>A<<

7.

Charge air cooler outlet hose E

Headlight support panel cover
(Refer to GROUP 51, Front
Bumper and Radiator Grille
Assembly

P.51-15

)

8.

Charge air cooler intake pipe B

<<A>>

>>A<<

9.

Charge air cooler intake hose D

Removal steps (Continued)

Front bumper and radiator grille
assembly (Refer to GROUP 51,
Front Bumper and Radiator Grille
Assembly

P.51-15

)

10. Charge air cooler outlet pipe C

<<A>>

>>A<<

11. Charge air cooler outlet hose C
12. Charge air cooler hanger bracket

(LH)

13. Charge air cooler hanger
14. Charge air cooler assembly

Removal steps (Continued)

AC808511

Air pipe

AD

Mating marks

Air hose

AC708399

Stopper end

AF

Stopper

Bulge

Hose clamp

5 ± 1 mm
(0.20 ± 0.04 in)

CHARGE AIR COOLER

TSB Revision

INTAKE AND EXHAUST

15-14

CAUTION

Do not use an electric screwdriver or air tool. Manually
tighten the hose clamp.
3. Align the mating marks on the air hose, air pipe, and hose

clamp. Then, tighten the hose clamp to the specified torque.

Tightening torque: 6.0 ± 1.0 N⋅ m (54 ± 8 in-lb)

AC808511

Air pipe

AD

Mating marks

Air hose
