CROSSMEMBER BAR
FRONT SUSPENSION
33-17
STABILIZER LINK BALL JOINT TURNING
TORQUE CHECK
AC001129
MB990326
AB
1. After shaking the ball joint stud several times,
install the nut to the stud and use special tool
preload socket (MB990326) to measure the
turning torque of the ball joint.
Standard value: 1.7
− 3.2 N⋅m
2. When the measured value exceeds the standard
value, replace the stabilizer link.
3. When the measured value is lower than the
standard value, check that the ball joint turns
smoothly without excessive play. If so, it is
possible to re-use that ball joint.
STABILIZER LINK BALL JOINT DUST
COVER CHECK
1. Check the dust cover for cracks or damage by
pushing it with your finger.
2. If the dust cover is cracked or damaged, replace
the stabilizer link.
NOTE: Cracks or damage of the dust cover may
cause damage to the ball joint.
CROSSMEMBER BAR
REMOVAL AND INSTALLATION
M1332016100086
AC310742
Front axle crossmember bar
AB
49 ± 10 N·m
