DOOR MIRROR

EXTERIOR

51-37

DOOR MIRROR CONTROL SWITCH CON-
TINUITY CHECK

AC005970

2

1

4

3

5

10

9

8

7

6

11

Switch position

Tester
connection

Specified
condition

OFF

− 2, 9 − 3, 9 − 6,

− 10, 9 − 11, 1 −

2, 1

− 3, 1 − 6, 1 −

10, 1

− 11

Open circuit

Left side OFF

− 6, 9 − 10, 9 −

11, 1

− 6, 1 − 10,

− 11

Open circuit

Up

− 6, 9 − 11

Less than 2
ohms

Down

− 11, 6 − 9

Right

− 6, 9 − 10

Left

− 10, 6 − 9

Right
side

OFF

− 2, 9 − 3, 9 − 6,

− 2, 1 − 3, 1 − 6

Open circuit

Up

− 6, 3 − 9

Less than 2
ohms

Down

− 3, 6 − 9

Right

− 6, 2 − 9

Left

− 2, 6 − 9

HEATED DOOR MIRROR CHECK

CAUTION

When relocating the car between locations with
extremely different temperatures (warm and
cold), leave the car in the location for a while to
adapt to the temperature prior to checking it.

AC202548

1

4 5 6 7

2 3

The resistance value between door mirror connector
terminals 1 and 4 should meet the standard value
with the ambient temperature at a steady 25

°C.

Standard value: 5.9

 7.8

NOTES

13A-1

GROUP 13A

MULTIPORT FUEL



INJECTION (MPI)

CONTENTS

GENERAL INFORMATION . . . . . . . .

13A-2

SERVICE SPECIFICATIONS. . . . . . .

13A-5

SPECIAL TOOLS. . . . . . . . . . . . . . . .

13A-6

TROUBLESHOOTING . . . . . . . . . . . .

13A-9

DIAGNOSIS TROUBLESHOOTING FLOW

13A-9

DIAGNOSIS FUNCTION. . . . . . . . . . . . . . .

13A-9

INSPECTION CHART FOR DIAGNOSIS



CODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

13A-17

INSPECTION PROCEDURE FOR DIAGNOSIS
CODES . . . . . . . . . . . . . . . . . . . . . . . . . . . .

13A-19

INSPECTION CHART FOR TROUBLE



SYMPTOMS . . . . . . . . . . . . . . . . . . . . . . . .

13A-233

SYMPTOM PROCEDURES . . . . . . . . . . . .

13A-237

DATA LIST REFERENCE TABLE  . . . . . . .

13A-372

ACTUATOR TEST REFERENCE TABLE. .

13A-378

CHECK AT THE ENGINE-ECU



TERMINALS . . . . . . . . . . . . . . . . . . . . . . . .

13A-379

INSPECTION PROCEDURE USING



OSCILLOSCOPE  . . . . . . . . . . . . . . . . . . . .

13A-385

ON-VEHICLE SERVICE. . . . . . . . . . .

13A-395

THROTTLE BODY (THROTTLE VALVE



AREA) CLEANING . . . . . . . . . . . . . . . . . . .

13A-395

THROTTLE POSITION SENSOR



ADJUSTMENT  . . . . . . . . . . . . . . . . . . . . . .

13A-395

BASIC IDLE SPEED ADJUSTMENT  . . . . .

13A-396

FUEL PRESSURE TEST  . . . . . . . . . . . . . .

13A-396

FUEL PUMP CONNECTOR DISCONNECTION



(HOW TO REDUCE PRESSURIZED FUEL



LINES). . . . . . . . . . . . . . . . . . . . . . . . . . . . .

13A-398

FUEL PUMP OPERATION CHECK  . . . . . .

13A-399

COMPONENT LOCATION  . . . . . . . . . . . . .

13A-400

ENGINE CONTROL RELAY CONTINUITY



CHECK  . . . . . . . . . . . . . . . . . . . . . . . . . . . .

13A-401

FUEL PUMP RELAY CONTINUITY CHECK

13A-402

FUEL PUMP RESISTOR CHECK . . . . . . . .

13A-403

INTAKE AIR TEMPERATURE SENSOR



CHECK  . . . . . . . . . . . . . . . . . . . . . . . . . . . .

13A-403

ENGINE COOLANT TEMPERATURE



SENSOR CHECK . . . . . . . . . . . . . . . . . . . .

13A-403

THROTTLE POSITION SENSOR CHECK .

13A-404

OXYGEN SENSOR CHECK . . . . . . . . . . . .

13A-404

INJECTOR CHECK . . . . . . . . . . . . . . . . . . .

13A-406

INJECTOR RESISTOR CHECK . . . . . . . . .

13A-407

IDLE SPEED CONTROL SERVO



(STEPPER MOTOR) CHECK . . . . . . . . . . .

13A-408

FUEL PRESSURE SOLENOID VALVE



CHECK  . . . . . . . . . . . . . . . . . . . . . . . . . . . .

13A-409

OIL FEEDER CONTROL VALVE CHECK. .

13A-410

INJECTOR  . . . . . . . . . . . . . . . . . . . . .

13A-411

REMOVAL AND INSTALLATION  . . . . . . . .

13A-411

THROTTLE BODY ASSEMBLY . . . . .

13A-413

REMOVAL AND INSTALLATION  . . . . . . . .

13A-413

ENGINE CONTROL RESISTOR,



RELAY  . . . . . . . . . . . . . . . . . . . . . . . .

13A-415

REMOVAL AND INSTALLATION  . . . . . . . .

13A-415

ENGINE-ECU  . . . . . . . . . . . . . . . . . . .

13A-416

REMOVAL AND INSTALLATION  . . . . . . . .

13A-416

GENERAL INFORMATION

MULTIPORT FUEL INJECTION (MPI)

13A-2

GENERAL INFORMATION

M1131000102428

The Multipoint Fuel Injection System consists of sen-
sors which detect the engine conditions, the
engine-ECU which controls the system based on sig-
nals from these sensors, and actuators which oper-
ate under the control of the engine-ECU. The

engine-ECU carries out activities such as fuel injec-
tion control, idle speed control and ignition timing
control. In addition, the engine-ECU is equipped with
several diagnosis modes which simplify trouble-
shooting when a problem develops.

FUEL INJECTION CONTROL

The injector drive times and injector timing are con-
trolled so that the optimum air/fuel mixture is sup-
plied to the engine to correspond to the
continually-changing engine operation conditions.
A single injector is mounted at the intake port of each
cylinder. Fuel is sent under pressure from the fuel
tank by the fuel pump, with the pressure being regu-
lated by the fuel pressure regulator. The fuel thus
regulated is distributed to each of the injectors.
 Fuel injection is normally carried out once for each
cylinder for every two rotations of the crankshaft. The
firing order is 1-3-4-2. This is called sequential fuel
injection. The engine-ECU provides a richer air/fuel
mixture by carrying out "open-loop" control when the

engine is cold or operating under high load condi-
tions in order to maintain engine performance. In
addition, when the engine is warm or operating under
normal conditions, the engine-ECU controls the
air/fuel mixture by using the oxygen sensor signal to
carry out "closed-loop" control in order to obtain the
theoretical air/fuel mixture ratio that provides the
maximum cleaning performance from the three way
catalyst.

IDLE SPEED CONTROL

The idle speed is kept at the optimum speed by con-
trolling the amount of air that bypasses the throttle
valve in accordance with changes in idling conditions
and engine load during idling. The engine-ECU
drives the idle speed control motor to keep the
engine running at the pre-set idle target speed in
accordance with the engine coolant temperature and

air conditioner load. In addition, when the air condi-
tioner switch is turned off and on while the engine is
idling, the idle speed control motor operates to adjust
the throttle valve bypass air amount in accordance
with the engine load conditions in order to avoid fluc-
tuations in the engine speed.

IGNITION TIMING CONTROL

The power transistor located in the ignition primary
circuit turns ON and OFF to control the primary cur-
rent flow to the ignition coil. This controls the ignition
timing in order to provide the optimum ignition timing
with respect to the engine operating conditions. The
ignition timing is determined by the engine-ECU from
the engine speed, intake air volume, engine coolant
temperature and atmospheric pressure.

SELF-DIAGNOSIS FUNCTION

• When an abnormality is detected in one of the

sensors or actuators related to emission control,
the engine warning lamp (check engine lamp)
illuminates as a warning to the driver.

• When an abnormality is detected in one of the

sensors or actuators, a diagnosis code corre-
sponding to the abnormality is output.

• The RAM data inside the engine-ECU that is

related to the sensors and actuators can be read
by means of the M.U.T.-II/III. In addition, the actu-
ators can be force-driven under certain circum-
stances.
