Mitsubishi Lancer Evolution IX. Manual - part 54

ANTI-SKID BRAKING SYSTEM (ABS)

CIRCUIT DIAGRAMS

90-195

4WD-ECU

Wire colour code
B : Black     LG : Light green
G : Green     L : Blue
W : White     Y : Yellow
SB : Sky blue     BR : Brown
O : Orange     GR : Grey
R : Red     P : Pink
V : Violet     PU : Purple

ANTI-SKID BRAKING SYSTEM (ABS)

CIRCUIT DIAGRAMS

90-196

ANTI-SKID BRAKING SYSTEM (ABS) <LH drive vehicles> (CONTINUED)

PARKING
BRAKE
SWITCH

ABS-ECU

DIAGNOSIS
CONNECTOR

FUSIBLE
LINK

1

ACD AND AYC

FRONT SIDE

ANTI-SKID BRAKING SYSTEM (ABS)

CIRCUIT DIAGRAMS

90-197

NOTES

ANTI-SKID BRAKING SYSTEM (ABS)

CIRCUIT DIAGRAMS

90-198

ANTI-SKID BRAKING SYSTEM (ABS)



<RH drive vehicles>

M1901008401315

ABS-ECU

COMBI-
NATION
METER

IGNITION
SWITCH (IG2)

IGNITION
SWITCH (IG1)

FUSIBLE
LINK

3

SOLENOID
VALVE POWER
SOURCE

MOTOR
POWER
SOURCE

POWER
SOURCE

·ENGINE CONTROL
 SYSTEM
·ENGINE OIL LEVEL
 WARNING LAMP
·HEADLAMP
·METER AND GAUGE
·REAR FOG LAMP
·TAIL LAMP, POSITION
 LAMP, LICENCE PLATE
 LAMP AND LIGHTING
 MONITOR BUZZER
·TURN-SIGNAL LAMP
 AND HAZARD
 WARNING LAMP
·WINDSHIELD WIPER
 AND WASHER
