CIRCUIT DIAGRAMS - EQUIPMENT

3-149

Connector lock switch*

Connector lock switch*

Warning light
drive circuit

Connector lock
detection circuit

Squib drive circuit

Squib drive circuit

Connector lock
switch*

Connector lock
switch*

Connector
lock switch*

Connector
lock switch*

Seat belt
pretensioner (RH)

Seat belt
pretensioner (LH)

Microcomputer

CIRCUIT DIAGRAMS - EQUIPMENT

3-150

SRS airbag, pretensioners <vehicle not fitted with passenger seat airbag>
(continued)

Fusible
link

Microcomputer

Interface circuit

MUT interface
circuit

Diagnostic
connector

Front impact sensor (RH)

Front impact sensor (LH)

Front view

CIRCUIT DIAGRAMS - EQUIPMENT

3-151

<Memo>

CIRCUIT DIAGRAMS - EQUIPMENT

3-152

SRS airbag, pretensioners <vehicle fitted with passenger seat airbag>

M3030009800167

Fusible
link

Ignition switch (IG1)

Combination
meter

DVD-MMCS
Windscreen wiper/washer
Engine control system
Gauge
Indicator light, hazard warning
light
Tail light, front side light, licence
plate light, lighting monitor
buzzer

Remote control door
mirror
Fog light
Headlight
Rear wiper/washer
Interior light, luggage
compartment light,
ignition lock light, door
open warning light

Back-up
capacitor

DC-DC
converter

Power
distribution
circuit

Front airbag
analogue G sensor

MUT interface
circuit

Front airbag
analogue G sensor

Squib drive
circuit

Connector
lock switch*

Clock
spring

Connector
lock switch*

Diagnostic
connector

Connector
lock switch*

Driver seat
airbag
module
(squib)

Note:
*:When connector
inserted: ON
When connector
removed: OFF
