Mitsubishi Lancer Evolution 8 MR. Manual - part 13





Title

No.

Issue date

Title

No.

Issue date

New model manuals

Body Service Manuals

•

Mirage, Lancer

1036F30

10/1995

•

Mirage, Lancer

(supplement)

1036F52

8/1996

•

Mirage, Lancer

1036F31

1/1996

•

Lancer Sedia

1036K50

5/2000

•

Mirage, Lancer

1036F32

8/1996

•

Lancer Sedia

(supplement)

1036K51

7/2000

•

Mirage, Lancer

1036F33

7/1997

•

Lancer Evolution VII

(supplement)

1036K52

5/2001

•

Lancer

1036F34

1/1998

•

Lancer Sedia

(supplement)

•

Lancer Evolution VIII

MR (supplement)

1036K53

1036K54

10/2001

2/2004

•

Mirage, Lancer

1036F35

10/1998

•

Lancer

1036F36

1/1999

•

Lancer

1036F37

12/1999

•

Lancer Sedia

1036K30 5/2000

•

Lancer Sedia

1036K31 7/2000

•

Lancer Evolution VII

1036K32 1/2001

Wiring layout diagram

Service Manuals

•

Lancer Sedia

1036K33 5/2001

•

Lancer Evolution VIII

1036K77

1/2003

•

Lancer Sedia

1036K34 5/2001

•

Lancer Evolution VIII

MR (supplement)

1036K80

2/2004

•

Lancer Evolution VII

1036K35 1/2001

•

Lancer Sedia

1036K36 5/2002

•

Lancer Evolution VIII

1036K37 1/2003

•

Lancer

1036K38 2/2003

•

Lancer

1036K39 12/2003

•

Lancer Evolution VIII MR

1036K40 2/2004

Service Manuals

Engine Service Manuals

•

Lancer Sedia

1036K00 5/2002

•

4G6 Engine

1039G46 1/2001

•

Lancer Sedia

1036K01 7/2000

•

4G6 Engine

1039G63 1/2003

•

Lancer Evolution VII

(supplement)

1036K02 1/2001

•

Lancer Sedia (supplement)

1036K03 5/2001

•

Lancer Sedia (supplement)

1036K04 10/2001

Transmission Service

Manuals

•

Lancer Evolution VII

(supplement)

1036K05 1/2002

•

W5M51 Manual

Transmission

1039M17 1/2001

•

Lancer Sedia (supplement)

1036K06 5/2002

•

W5M51Manual

transmission

(Supplement)

1039M22 1/2003

•

Lancer Evolution VIII

(supplement)

1036K07 1/2003

•

W6MAA Manual

transmission

1039M23 1/2003

•

Lancer (supplement)

1036K08 2/2003

•

Lancer (supplement)

1036K09 12/2003

Related information

Precautions to be taken when servicing vehicles with seatbelts fitted with SRS Airbag and Pretensioners:

1. Incorrect inspection or servicing of SRS airbag and pretensioner fitted seatbelt parts, as well as any related

components, could lead to major damage or non-operation as a result of sudden, unintentional operation of SRS
airbag and pretensioner fitted seatbelts (incorrect deployment).

2. In cases where heating from painting processes occurs, the SRS-ECU, driver side airbag module, passenger side

airbag module, pre-tensioner fitted seatbelts, and cross springs, should be removed.
•  93°C and above: SRS-ECU, driver side airbag module, passenger side airbag module, cross springs
•  90°C and above: pretensioner fitted seatbelts

3. Inspections and servicing of SRS airbag and pretensioner fitted seatbelt parts and any related components must,

without fail, be done by a Mitsubishi Motors authorized dealer.

4. Inspections and servicing of SRS airbag and pretensioner fitted seatbelt parts and any related components must be

done paying scrupulous attention to the relevant service manual (particularly in the case of Group 52B – SRS
airbags).

00-1

GENERAL – MODEL COMPOSITION, APPLIED VEHICLE NUMBERS

SECTION 00

GENERAL

CONTENTS

Model composition ....................................1

Applied vehicle numbers ..........................1

Model line-up

Note

¡

= Continued model

Applied vehicles

GH-CT9A: CT9A-0300001 ~

Model

Version

’04 Model Grade

Engine Model

Transmission

Fuel System

GH-CT9A

SNDFZ

SJDFZ

SJGFZ

¡

¡

¡

RS

RS

GSR

4G63
(2 000 DOHC 16 valve
intercooler turbo)

W5M51 (4WD, 5M/T)

W6MAA (4WD, 6 M/T)

MPI

MPI- General

13A-2

General

Service information issued contains the changes noted below. Other service details remain unchanged.
•

Change from one to two wastegate solenoid valves. However, the No.2 wastegate solenoid valve on the 5 M/T is not
functional.

•

Diagnosis code No. P1500 changed to P0622. <6M/T>

MPI system diagram

★

1. O2 sensor

★

2. Air flow sensor

★

3. Air intake sensor

★

4. Throttle position

sensor

★

5. Cam position sensor

★

6. Crack angle sensor

★

7. Barometric pressure

sensor

★

8. Water temperature

sensor

★

9. Knock sensor

• Power supply
•  Ignition switch IG
• Ignition switch ST
• Vehicle speed sensor
• A/C switch
• A/C load signal
• Power steering fluid

pressure switch

• Alternator FR signal
• Intercooler water spray

switch (auto)

• Intercooler water spray

switch (manual)

✩

1. Injector

✩

2. ISC servo (stepper

motor)

✩

3. Fuel pressure  control

solenoid valve

✩

4. No.1 wastegate solenoid

valve

✩

5. No.2 wastegate solenoid

valve

✩

6. Purge control solenoid

valve

✩

7. Secondary air control

solenoid valve

• Engine control relay
• Fuel pump relay 2, 3
• A/C relay
• Ignition coil
• Fan controller
• Condenser fan relay (HI)
• Condenser fan relay

(LOW)

• Engine warning lamp
• Diagnosis output
• Alternator G terminal
• Intercooler water spray

relay

• Intercooler water spray

lamp

Engine ECU

✩

6. Purge control

solenoid valve

Canister

✩

7. Secondary air

control solenoid valve

From fuel tank

Secondary
air valve

By-pass
valve

★

1. O

2

sensor

✩

3. Fuel pressure

control solenoid valve

★

4. Throttle
position

sensor

★

7. Barometric pressure

sensor

★

3. Air intake

sensor

★

2. Air flow sensor

✩

4. No.1

wastegate

solenoid valve

✩

5. No.2 wastegate

solenoid valve

Only operates on 6M/T

Wastegate actuator

Fuel pressure
regulator

✩

1. Injector

★

5.Cam position sensor

★

8.Water temperature sensor

★

9.Knock sensor

Crack angle sensor

Catalytic converter

Air

intake

Check

valve

✩

2. ISC servo

Vacuum
tank

From fuel
pump

To fuel
tank
