Mitsubishi Lancer Evolution VI. Manual - part 132

SINGLE PART INSTALLATION POSITION –

Relay

B

Fuel pump relay No.2

AYC relay

C

Radiator fan
motor relay (LO)

C-16

SINGLE PART INSTALLATION POSITION

RELAY

Name

Symbol

Name

Symbol

AYC relay

B

Fuel pump relay No.2

B

Condenser fan motor relay (HI)

A

Radiator fan motor relay (HI)

A

Condenser fan motor relay (LO)

A

Radiator fan motor relay (LO)

C

A

Condenser fan motor
relay (LO)

Condenser fan motor
relay (HI)

Radiator fan motor
relay (HI)

SINGLE PART INSTALLATION POSITION –

ECU / Sensor

C-17

ECU

B21A066

SENSOR

Name

Symbol

Name

Symbol

Acceleration sensor (lateral) <vehicles with
AYC>

I

Knock sensor

B

Acceleration sensor (longitudinal) <vehicles
with ABS and AYC>

I

Outside air temperature sensor <vehicles with
fully automatic air conditioner>

F

Air flow sensor

D

O

2

 sensor

E

Camshaft position sensor

G

Steering angle sensor (lateral) <vehicles with
AYC>

H

Crank angle sensor

A

Throttle position sensor

C

Engine coolant temperature sensor

G

B21A066

SINGLE PART INSTALLATION POSITION –

Sensor

A

Crank angle sensor

B

Knock sensor

C

Throttle position
sensor

D

Air flow sensor

E

O

2

 sensor

F

Outside air
temperature sensor

G

Engine coolant
temperature sensor

Camshaft position
sensor

H

Steering angle sensor

I

Acceleration
sensor
(longitudinal)

Acceleration sensor
(lateral)

C-18

SINGLE PART INSTALLATION POSITION –

Solenoid and Solenoid Valve

A

Intake manifold
stay

Secondary
air control
solenoid
valve

B

Fuel pressure
solenoid valve

C

Waste gate
solenoid valve

D

Rear combination
lamp (RH)

Direction valve

Proportioning
valve

C-19

SOLENOID AND SOLENOID VALVE

Name

Symbol

Name

Symbol

Direction valve <vehicles with AYC>

D

Secondary air control solenoid valve

A

Fuel pressure solenoid valve

B

Waste gate solenoid valve

C

Proportioning valve <vehicles with AYC>

D

DOM0011
