STEERING –
Power Steering Gear Box
37A-8
DISASSEMBLY AND REASSEMBLY
Steering gear seal set
Flare nut
1
3
4
5
6
7
8
9
10
11
12
13
14
15
17
19
21
24
25
26
29
32
33
35
2
22
34
16
27
28
31
30
13 Nm
1
20
36
37
18
25 Nm
49 – 59 Nm
88 Nm
27
28
30
9
20
6
2
9
6
35
59 Nm
15
59 Nm
21 Nm
2
31
18
23
23
Disassembly steps
1. Feed pipe
2. O-ring
"
N
A
3. Tie-rod end locking nut
"
N
A
4. Tie-rod end
5. Bellows clip
"
M
A
6. Bellows band
7. Bellows
"
L
A
8. Tie-rod
"
L
A
9. Tab washer
"
K
A D
Total pinion torque adjustment
10. Locking nut
A
A
"
11. Rack support cover
12. Rack support spring
13. Rack support
"
J
A
14. End plug
15. Self-locking nut
16. Bolt
17. Valve assembly
A
B
" "
I
A
18. Oil seal
A
B
"
19. Pinion and valve assembly
A
C
" "
H
A
20. Seal ring
21. Valve housing assembly
A
D
" "
G
A
22. Ball bearing
A
D
" "
G
A
23. Oil seal
A
E
" "
F
A
24. Circlip
A
F
"
25. Rack stopper
A
F
" "
E
A
26. Rack bushing
A
G
" "
E
A
27. Oil seal
28. O-ring
A
F
" "
D
A
29. Rack
30. Piston ring
31. O-ring
32. Rack housing assembly
A
H
" "
C
A
33. Ball bearing
A
I
" "
C
A
34. Needle roller bearing
A
J
" "
B
A
35. Oil seal
36. Gear housing mounting bushing
"
A
A
37. Gear housing mounting rubber
