Mitsubishi Fuso Canter. Manual - part 8
Spec. No. FE71/73, 11/11
CAB
INTERIOR
AM radio
DIN size radio fitted to instrument panel, electronic tuning type,
with digital clock and one speaker
AM/FM radio, stereo
DIN size radio fitted to instrument panel, electronic tuning type,
with digital clock and two speakers
AM/FM radio & cassette stereo
DIN size radio fitted to instrument panel, electronic tuning type,
with digital clock and cassette player with two speakers
Armrest for driver's seat
Adjustable type
Cigarette lighter
Electric type
Door pockets
Driver and passenger side
Fabric seat
Deluxe type seat
Floor mat
Carpet type. Only for R.H.D. model
Full trim
Side trim, rear pillar trim & rear panel trim. Installing "Seat belts" is necessary
Interior rear view mirror
Flat type
Large room lamp
10W x 1
Overhead shelf
Installed on right side
Seat back tray and
Tray on window side and center passenger seat back,
back panel console
console on back panel
Seat belts
Driver and window side passenger
…
3 point type with ELR
Center
…
2 point type
Sun visor
For window side passenger
Urethane foam steering wheel
Surface material: Urethane foam rubber
EXTERIOR
Fog lamps
White (35W x 2), fitted to front bumper
Under view mirror
Opposite to driver side
INSTRUMENT
Air conditioner
4.18 kW (3,600 kcal/h, 15,070 kJ/h), manual control type, includes heater
and defroster
Heater and defroster
4.47 kW (3,850 kcal/h, 16,116 kJ/h), manual control type
Power windows
Driver and passenger side
Tachometer
Electric driven type
2-DIN box with lid
Total 5-DIN space is provided
CHASSIS
Exhaust brake
Vacuum operated, butterfly valve type
Heavy duty battery
80 Ah (288 kC) at 20 hr rate (95D31L) x 2
64 Ah (230 kC) at 5 hr rate (95D31L) x 2
FE71P/73P SERIES OPTIONAL EQUIPMENT
Lockable fuel tank cap
For protection from fuel thief
Power steering *
Integral type hydraulic power booster
Radial tire
Reverse warning buzzer
Synchronized with reverse gear of transmission
Spare tire
Spare tire carrier
Not available for FE71PBN4
Stabilizer, front
Only for FE71PB8
Standard tool set
ENGINE
Tool box
Fitted to side frame (only for FE73PE6)
Tool box with padlock
Fitted to side frame (only for FE73PE6)
Glow plugs with indicator
To assist easy engine starting in cold season or area
Fuel/Oil filter
Center bolt type, replaceable paper element
Heavy duty spring, rear
(only for FE73P)
Heavy duty spring, front
(only for FE73P)
11 mm
-4
0.43 in.
Main: 1,250 mm x 70 mm x
(49.2 in. x 2.76 in. x
)
10 mm
-1
0.39 in.
8 mm
-4
0.31 in.
Helper: 990 mm x 70 mm x
(39.0 in. x 2.76 in. x
)
9 mm
-2
0.35 in.
Ground rating: 2,200 kg (4,850 lb)
10 mm-2
0.39 in.
1,200 mm x 70 mm x
(47.2 in. x 2.76 in. x
)
11 mm-3
0.43 in.
Ground rating: 1,300 kg (2,865 lb)
Output capacity: 147 N·m (15 kgf·m,108 Ib·ft)/2,000 rpm (33.3 r/s)
Output speed: 0.683 x Engine speed
Rotation: Opposite engine
Control: Cable remote control
ANNOTATION
SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE.
* In case of FE71PB8, installing front stabilizer and changing tire size(7.00-15-8 PR
b 7.50-15-10 PR) are necessary.
Transmission P.T.O.
Combine with fuel injection pump to reduce black-smoke at high altitude
operation
With tube (Including spare tire carrier & spare tire. Excluding spare
tire carrier for FE71PBN4)
Transmission P.T.O. (on/off control lever type)
Tire–Lug pattern, Heavy duty springs
Altitude fuel compensator
Dump chassis package
OTHER
