CONVERTIBLE TOP

TSB Revision

BODY

42-155

TOPSTACK RAIL WEATHERSTRIP

REMOVAL AND INSTALLATION

M1426208600011

Pre-removal Operation

•

Completely open the convertible top.

•

Completely down the quarter window glass.

Post-installation Operation

•

Convertible Top Fit Adjustment (Refer to

P.42-130

.)

AC004158 AB

2

4

1

3

7

6

5

8

9

REMOVAL STEPS
1. TOPSTACK FRONT RAIL WEATH-

ERSTRIP

2. TOPSTACK FRONT RAIL WEATH-

ERSTRIP HOLDER

3 . SHIM
4. TOPSTACK CENTER RAIL WEATH-

ERSTRIP

5. TOPSTACK CENTER RAIL WEATH-

ERSTRIP

6. SHIM
7. TOPSTACK REAR RAIL WEATHER-

STRIP

8. TOPSTACK REAR RAIL WEATHER-

STRIP HOLDER

9. SHIM

REMOVAL STEPS (Continued)

CONVERTIBLE TOP

TSB Revision

BODY

42-156

CONVERTIBLE TOP SWITCH

REMOVAL AND INSTALLATION

M1426202400020

INSPECTION

M1426202500027

CONVERTIBLE TOP SWITCH CONTINUITY
CHECK

AC004159 AB

CONVERTIBLE TOP SWITCH

SWITCH
POSITION

TESTER
CONNECTION

SPECIFIED
CONDITION

CLOSE

4

−

 7

Continuity

OPEN

5

−

 7

Continuity

1

2

3

4

5

6

7

8

AC004160

CONVERTIBLE TOP

TSB Revision

BODY

42-157

CONVERTIBLE TOP CONTROL MODULE

REMOVAL AND INSTALLATION

M1426203000025

AC004161

1

REMOVAL STEPS

•

REAR SEAT BACK (REFER TO
GROUP 52A

−

 REAR SEAT

P.52A-

23

.)

1. CONVERTIBLE TOP CONTROL

MODULE

SPECIFICATIONS

TSB Revision

BODY

42-158

SPECIFIC ATIO NS

FASTENER TIGHTENING SPECIFICATIONS

M1426003000032

ITEMS

SPECIFICATIONS

Hood

Hood hinge bolt (hood side)

12

±

 2 N

⋅

m (100

±

 22 in-lb)

Hood hinge bolt (body side)

12

±

 2 N

⋅

m (100

±

 22 in-lb)

Hood latch bolt

8.9

±

 1.9 N

⋅

m (78

±

 17 in-lb)

Hood support rod bolt

4.9

±

 1.0 N

⋅

m (44

±

 8 in-lb)

Hood switch bolt

4.9

±

 1.0 N

⋅

m (44

±

 8 in-lb)

Quarter window
regulator

Quarter window regulator bolt

8

±

 1.5 N

⋅

m (71

±

 13 in-lb)

Door

Door check bolt

5.0

±

 1.0 N

⋅

m (44

±

 9 in-lb)

Door hinge bolt (door side)

21

±

 4 N

⋅

m (16

±

 3 ft-lb)

Door hinge bolt (body side)

26

±

 5 N

⋅

m (19

±

 3 ft-lb)

Door latch assembly screw

9.0

±

 2.0 N

⋅

m (80

±

 17 in-lb)

Striker screw

20

±

 4 N

⋅

m (15

±

 2 in-lb)

Liftgate

Liftgate gas spring bolt

12

±

 2 N

⋅

m (100

±

 2 in-lb)

Liftgate hinge bolt

21

±

 4 N

⋅

m (16

±

 3 in-lb)

Liftgate latch assembly screw

21

±

 4 N

⋅

m (16

±

 3 in-lb)

Striker bolt

21

±

 4 N

⋅

m (16

±

 3 in-lb)

Trunk lid

Striker bolt

22

±

 4 N

⋅

m (16

±

 3 ft-lb)

Trunk lid gas spring bolt

12

±

 2 N

⋅

m (104

±

 21 in-lb)

Trunk lid hinge bolt (trunk lid side)

13

±

 2 N

⋅

m (109

±

 21 in-lb)

Trunk lid hinge bolt (body side)

13

±

 2 N

⋅

m (109

±

 21 in-lb)

Trunk lid hinge nut

13

±

 2 N

⋅

m (109

±

 21 in-lb)

Trunk lid latch assembly bolt

22

±

 4 N

⋅

m (16

±

 3 ft-lb)

Sunroof

Guide block screw

2.0

±

 0.5 N

⋅

m (18

±

 4 in-lb)

Guide rail stopper screw

2.0

±

 0.5 N

⋅

m (18

±

 4 in-lb)

Sunroof motor assembly bolt

5.4

±

 1.5 N

⋅

m (48

±

 13 in-lb)

Sunroof drip rail screw

2.0

±

 0.5 N

⋅

m (18

±

 4 in-lb)

Sunshade stopper screw

1.4

±

 0.3 N

⋅

m (13

±

 3 in-lb)

2.0

±

 0.5 N

⋅

m (18

±

 4 in-lb)

Electric convertible
top

Balance link bolt

29

±

 3 N

⋅

m (22

±

 2 ft-lb)

Main pivot base assembly bolt

29

±

 3 N

⋅

m (22

±

 2 ft-lb)

No.1 bow bolt

29

±

 3 N

⋅

m (22

±

 2 ft-lb)

Topstack center rail assembly bolt

29

±

 3 N

⋅

m (22

±

 2 ft-lb)

53

±

 2 N

⋅

m (39

±

 2 ft-lb)

Topstack control link bolt

29

±

 3 N

⋅

m (22

±

 2 ft-lb)

Topstack front rail assembly bolt

29

±

 3 N

⋅

m (22

±

 2 ft-lb)

Topstack rear rail assembly bolt

53

±

 2 N

⋅

m (39

±

 2 ft-lb)
