TRANSAXLE (TRANSMISSION) TSB Revision MANUAL TRANSAXLE OVERHAUL 22B-19 >>D<< 5TH-REVERSE SPEED SHIFT FORK/5TH-REVERSE reverse speed shift rail and fork. 2. Fit each shift fork in the groove of synchronizer sleeve and install the shift fork and rail assembly. 3. Insert the 3rd-4th speed shift rail and 5th speed-reverse shift rail into the rail hole in the clutch housing. >>E<< SPRING PIN INSTALLATION 2. Insert the new spring pin. Push it in so that the slit and center axis of the rail are aligned. >>F<< SPACER AND OUTER RACE INSTALLATION BEFORE ASSEMBLY." 2. Using special tools MB990935 and MB990938, press install the outer race into the transaxle case. AKX00884AB 3RD-4TH SPEED 3RD-4TH SPEED 5TH-REVERSE 5TH-REVERSE AKX00885 5TH-REVERSE 3RD-4TH AB AKX00920 SHIFT FORK 2.5 mm (0.098 in) SHIFT RAIL SPRING AB AKX00815AB MB990938 MB990935 |
