IGNITION SYSTEM TSB Revision ENGINE ELECTRICAL 16-41 Point D: Ignition voltage height (distribution per each cylinder) shows ABNORMAL WAVEFORMS EXAMPLES • Wave characteristics • Cause of problem Example 2 • Wave characteristics • Cause of problem Example 3 • Wave characteristics • Cause of problem IGNITION PLUG CONDITION COMPRESSION CONCENTRATION IGNITION SPARK PLUG High Large Large wear High Lean Retarded High resistance Low Small Normal Low Rich Advanced Leak AKX00280 AKX00281 AKX00282 |
