ON-VEHICLE SERVICE
TSB Revision
MULTIPORT FUEL INJECTION (MFI) <3.0L ENGINE>
13B-547
O N -VEH IC LE SERVIC E
COMPONENT LOCATION
M1131002100064
MD998709
Adaptor hose
MIT210196
Measurement of fuel
pressure
MD998742
Hose adaptor
MD998742-01
MB991637
Fuel pressure gauge set
Tool not available
TOOL
TOOL NUMBER AND
NAME
SUPERSESSION
APPLICATION
MB991637
NAME
SYMBOL NAME
SYMBOL
Air conditioning compressor clutch relay K
Left bank heated oxygen sensor (front)
N
Crankshaft position sensor
A
Left bank heated oxygen sensor (rear)
M
Data link connector
T
Distributor (built-in camshaft position
sensor and ignition coil)
J
Manifold differential pressure sensor
F
EGR solenoid
B
Multiport fuel injection (MFI) relay/fuel
pump relay
K
Engine control module (ECM) <M/T>
U
Park/neutral position switch <A/T>
R
Engine coolant temperature sensor
Q
Powertrain control module <A/T>
U
Evaporative emission purge solenoid
B
Power steering pressure switch
L
Evaporative emission ventilation
solenoid
W
Right bank heated oxygen sensor (front)
C
Fan controller
O
Right bank heated oxygen sensor (rear)
E
Fuel tank differential pressure sensor
V
Throttle position sensor
H
Idle air control motor
I
Vehicle speed sensor
P
Injector
G
Volume air flow sensor (with built-in
intake air temperature sensor and
barometric pressure sensor)
S
Knock sensor
D
