Mitsubishi Eclipse / Eclipse Spyder (2000-2002). Service and repair manual - part 75
SPECIFICATIONS
TSB Revision
ENGINE LUBRICATION
12-7
CAUTION
Do not start the engine within one hour after the engine oil
pressure switch has been installed.
9. Use special tool MD998054 to tighten the oil pressure switch
to the specified torque.
Tightening torque:
<2.4L Engine> 19
±
3 N
⋅
m (14
±
2 ft-lb)
<3.0L Engine> 10
±
2 N
⋅
m (87
±
17 in-lb)
10.Install the oil pressure switch terminal.
SPECIFIC ATIO NS
FASTENER TIGHTENING SPECIFICATIONS
M1121002200082
SERVICE SPECIFICATIONS
M1121000300050
SEALANT
M1121000500054
LUBRICANTS
M1121000400091
AKX00294
MD998054
AB
ITEMS
SPECIFICATIONS
Engine oil filter
MD360935, MD352626
14
±
2 N
⋅
m (124
±
18 in-lb)
MD325714, MD332687,
MD365876
16
±
4 N
⋅
m (12
±
3 ft-lb)
MD136466, MD322508
17
±
3 N
⋅
m (13
±
2 ft-lb)
Engine oil pan grain plug
39
±
5 N
⋅
m (29
±
4 ft-lb)
Oil pressure switch
2.4L Engine
19
±
3 N
⋅
m (14
±
2 ft-lb)
3.0L Engine10
±
2 N
⋅
m (87
±
17 in-lb)
ITEM
STANDARD VALUE
Oil pressure kPa (psi)
at idle
29 (4.2) or more
at 3,500 r/min
294
−
686 (43
−
100)
ITEM
SPECIFIED SEALANT
Oil pressure switch
3M
AAD Part No. 8672 or equivalent
ITEMS
ENGINE OIL (API CLASSIFICATION)
QUANTITY dm
3
(qt)
Oil filter
SJ or higher
0.3 (0.32)
Total quantity
4.3 (4.5)
