EQUIPMENT   Lighting

Outer lens

MULTI-REFLECTOR

The reflector is divided into minor sections to produce an ade-
quate light pattern.

This design eliminates the lens cut from the outer lens, providing
a characteristic appearance.



 Meters



METERS AND GAUGES

The combination meter is of the plug-in type to

The speedometer is an electric type speedometer

tate its removal and installation. It is also a pointer

whose pointer moves smoothly without vibrations

type to provide good visibility.

in response to a pulse signal from the vehicle speed

The combination meter has large speedometer and

sensor as the speed changes.

tachometer located in the middle, with the fuel gauge,
engine coolant temperature gauge, boost gauge,

NOTE

and oil pressure gauge on both sides.

The indicator lamps and warning lamps vary on
different models.

<Turbo>

<Non-turbo>

Vehicles with
automatic transaxle

16X0955









The rotating shaft of the vehicle speed sensor is

mounted directly on the transaxle speedometer driv-

en gear. The rotation of the driven gear is transmitted
to a magnet via the rotating shaft. The

 built into

the Magneto Resistive Element (MRE) in the top
of the magnet detects the rotation of the magnet

and generates a

 electric signal for each

,

rotation of the speedometer driven gear.

NOTE
For the operation, refer to the 1991 3000GT Techni-
cal Information Manual (Pub. No. PXSE9001).

(built into MRE)

Magnet

Rotating shaft





The electric type speedometer uses an electronic
circuit to control the electric signal from the vehicle
speed sensor and a cross coil type speedometer
that has a magnet fixed to the pointer shaft and
two coils that pass directly through it. Furthermore,

the odometer and trip meter are directly driven by
the stepping motor with built-in gear.

NOTE
For the operation, refer to the 1991 3000GT Techni-
cal Information Manual (Pub. No.

Al



 and Washers







WINDSHIELD WIPERS AND WASHERS

The windshield wiper comes in two types; two speed

The washer nozzle is a



 type.

type with fixed interval intermittent function, and

l

The windshield washer tank is installed in the

two speed type with variable intermittent function.

L.H. side of the engine compartment on

They have the following characteristics.

bo vehicles and in the R.H. side of the luggage

l

The wiper motor and links are mounted as a

compartment on turbo vehicles.

unit on a frame to enhance the serviceability.

l

A washer interlocked wiper function and mist
wiper function have been adopted for greater
convenience.

<Turbo>

Frame

Windshield

Wiper blade

Wiper arm

washer

I

tank

Nozzle

Link

Washer hose

<Non-turbo>



 arm

Link

Al

Nozzle

Winbshield
washer
tank

 hose
