SPECIFICATIONS
TSB Revision
CLUTCH OVERHAUL
21B-11
SPECIFICATIONS
FASTENER TIGHTENING SPECIFICATIONS
M1212001800046
GENERAL SPECIFICATIONS
M1212000200104
SERVICE SPECIFICATIONS
M1212000300048
ITEMS
SPECIFICATIONS
Clutch cover mounting bolt
19
± 3 N⋅m (14 ± 2 ft-lb)
Clutch fluid line bracket bolt
19
± 3 N⋅m (14 ± 2 ft-lb)
Clutch release cylinder air bleeder <2.4L engine>
17
± 2 N⋅m (12 ± 1 ft-lb)
Clutch release cylinder air bleeder <3.0L engine>
11
± 2 N⋅m (8 ± 1 ft-lb)
Clutch release cylinder mounting bolt
19
± 3 N⋅m (14 ± 2 ft-lb)
Clutch release cylinder union bolt
23
± 2 N⋅m (17 ± 1 ft-lb)
Clutch tube flare nut
15
± 2 N⋅m (11 ± 1 ft-lb)
Fulcrum <2.4L engine>
35
± 6 N⋅m (26 ± 4 ft-lb)
Release fork shaft locking bolt <3.0L engine>
9.8
± 2 N⋅m (87 ± 17 in-lb)
ITEMS
SPECIFICATIONS
Clutch operating method
Hydraulic type
Clutch disc type
Single dry disc type
Clutch disc size OD x ID mm (in) <2.4L engine>
215 x 140 (8.46 x 5.51)
Clutch disc size OD x ID mm (in)
<3.0L engine without induction control valve>
225 x 150 (8.87 x 5.91)
Clutch disc size OD x ID mm (in)
<3.0L engine with induction control valve>
230 x 150 (9.06 x 5.91)
Clutch cover type
Diaphragm spring type
Clutch cover setting load N (lb) <2.4L engine>
4,539 (1,014)
Clutch cover setting load N (lb)
<3.0L engine without induction control valve>
5,864 (1,318)
Clutch cover setting load N (lb)
<3.0L engine with induction control valve>
5,860 (1317)
Clutch release cylinder ID mm (in) <2.4L engine>
19.05 (3/4)
Clutch release cylinder ID mm (in) <3.0L engine>
20.64 (13/16)
ITEMS
LIMIT
Clutch disc facing rivet sink mm (in)
Minimum 0.3 (0.012)
Diaphragm spring end height difference mm (in)
0.5 (0.020)
