SPECIFICATIONS
TSB Revision
ENGINE OVERHAUL <3.0L>
11D-61
SEALANTS AND ADHESIVES
M1113000500220
Piston ring to ring groove clearance
mm (in)
No.1
0.03
− 0.07 (0.0012 − 0.0027) 0.1 (0.003)
No.2
0.02
− 0.06 (0.0008 − 0.0023) 0.1 (0.003)
Piston ring end gap mm
(in)
With
variable
induction
system
No.1
0.25
− 0.35 (0.009 − 0.013)
0.8 (0.03)
No.2
0.35
− 0.50 (0.013 − 0.019)
0.8 (0.03)
Oil ring side
rail
0.10
− 0.35 (0.003 − 0.013)
1.0 (0.03)
Without
variable
induction
system
No.1
0.30
− 0.45 (0.012 − 0.017)
0.8 (0.03)
No.2
0.45
− 0.60 (0.018 − 0.023)
0.8 (0.03)
Oil ring side
rail
0.20
− 0.60 (0.008 − 0.023)
1.0 (0.03)
Piston pin outside diameter mm (in)
22.0 (0.87)
−
Piston pin press-in load N (lb) (room temperature)
7,350
− 17,200
(1,653
− 3,866)
−
Crankshaft pin oil clearance mm (in)
0.02
− 0.05 (0.0008 − 0.0019) 0.1 (0.003)
Connecting rod big end side clearance mm (in)
0.10
− 0.25 (0.003 − 0.009)
0.4 (0.02)
Crankshaft and cylinder block
Crankshaft end play mm (in)
0.05
− 0.25 (0.002 − 0.009)
0.3 (0.01)
Crankshaft journal outside diameter mm (in)
60 (2.4)
−
Crankshaft pin outside diameter mm (in)
50 (2.0)
−
Crankshaft journal oil clearance mm (in)
0.02
− 0.04 (0.0008 − 0.0015) 0.1 (0.003)
Piston to cylinder clearance mm (in)
0.02
− 0.04 (0.0008 − 0.0015) −
Cylinder block flatness of gasket surface mm (in)
0.05 (0.02)
0.1 (0.003)
Cylinder block grinding limit of gasket surface mm
(in) total resurfacing depth of both cylinder head and
cylinder block
−
0.2 (0.008)
Cylinder block overall height mm (in)
210.5 (8.29)
−
Cylinder bore inside diameter mm (in)
91.1 (3.59)
−
Cylindricity mm (in)
0.01 (0.0003)
−
ITEM
STANDARD VALUE
LIMIT
ITEM
SPECIFIED SEALANT
QUANTITY
Intake manifold upper
MITSUBISHI Genuine part No.MD970389,
3M
AAD Part No. 8660 or equivalent
As required
Engine coolant temperature
sensor
3M
AAD Part No. 8731 or equivalent
As required
Engine coolant temperature
gauge unit
3M
AAD Part No. 8672 or equivalent
As required
Oil pressure switch
3M
AAD Part No. 8672 or equivalent
As required
Oil pump case
MITSUBISHI Genuine part No. MD970389 or equivalent
As required
Oil pan
MITSUBISHI Genuine part No. MD970389 or equivalent
As required
Oil seal case
MITSUBISHI Genuine part No. MD970389 or equivalent
As required
