AUTOMATIC TRANSAXLE DIAGNOSIS TSB Revision AUTOMATIC TRANSAXLE 23A-225 STEP 8. Measure the supply voltage at A/T control B-40. (2) Turn the ignition switch to the "ON" position. (3) Measure the voltage between harness connector B-40 terminal 9 and ground. • The voltage should equal battery positive voltage. (4) Turn the ignition switch to the "LOCK" (OFF) position. YES : Go to Step 11. STEP 9. Check A/T control relay connector A-17X in the YES : Go to Step 10. GROUP 00E, Harness Connector Inspection ACX02479 CONNECTOR: B-40 AK B-40 AC001967AT B-40 HARNESS AC102447AF BATTERY CONNECTOR: A-17X A-17X FRONT OF VEHICLE ACX02479 CONNECTOR: B-40 AK B-40 |
