OTHER DEVICES
TSB Revision
COMPONENT LOCATIONS
70-21
OTHER DEVICES
M1701005600186
NAME
SYMBOL NAME
SYMBOL
A/C compressor assembly (built-in A/C
refrigerant temperature switch) <2.4L
Engine>
D
Idle air control motor <3.0L Engine>
F
A/C compressor assembly (built-in A/C
refrigerant temperature switch) <3.0L
Engine>
G
Power steering pressure switch <2.4L
Engine>
C
Dual pressure switch
A
Power steering pressure switch <3.0L
Engine>
E
Idle air control motor <2.4L Engine>
B
AC102271
<2.4L ENGINE>
AB
A
B
A
D
C
E
F
<3.0L ENGINE>
G
AC003110
A
AB
HEADLIGHT (RH)
DUAL
PRESSURE
SWITCH
ACX02519
B
AB
IDLE AIR
CONTROL MOTOR
<2.4L ENGINE>
