MULTIPORT FUEL INJECTION (MFI) DIAGNOSIS

TSB Revision

MULTIPORT FUEL INJECTION (MFI) <2.4L>

13A-849

STEP 8. Measure the power supply voltage at ECM harness
side connector C-53 <M/T> or PCM harness side connector
C-54 <A/T>.
(1) Disconnect the connector C-53 <M/T> or C-54 <A/T> and

measure at the harness side.

AK300417

34 33 32

36 35

37

42

45

31

39

38

46

40

41

43

44

CONNECTOR: C-53 <M/T>

C-53 (G)

AB

HARNESS CONNECTOR:
COMPONENT SIDE

AK300412

42

43

48

49

50

51

52

53

54

55

56

57

46 45 44

58

59

60

61

62

63

64

65

66

47

41

C-54 (GR)

CONNECTOR: C-54 <A/T>

AB

HARNESS CONNECTOR:
COMPONENT SIDE

MULTIPORT FUEL INJECTION (MFI) DIAGNOSIS

TSB Revision

MULTIPORT FUEL INJECTION (MFI) <2.4L>

13A-850

(2) Measure the voltage between terminal No. 38 <M/T> or No.

49 <A/T> and ground.

• Voltage should be battery positive voltage.

Q: Is battery positive voltage (approximately 12 volts)

present?
YES : Go to Step 9.
NO :  Repair harness wire between MFI relay connector

A-18X (terminal No. 3) and ECM connector C-53
(terminal No. 38) <M/T> or PCM connector C-54
(terminal No. 49) <A/T> because of open circuit. Then
confirm that the malfunction symptom is eliminated.

AK000405

<M/T>

C-53 HARNESS
CONNECTOR:
COMPONENT SIDE

AI

31

32

33

34

35

36

37

38

39

40

41

42

43

44

45

46

AK000406AL

41

42

43

44

45

46

47

48

49

50

51

52

53

54

55

56

57

58

59

60

61

62

63

64

65

66

<A/T>

C-54 HARNESS
CONNECTOR:
COMPONENT SIDE

MULTIPORT FUEL INJECTION (MFI) DIAGNOSIS

TSB Revision

MULTIPORT FUEL INJECTION (MFI) <2.4L>

13A-851

STEP 9. Measure the power supply voltage at ECM harness
side connector C-49, C-53 <M/T> or PCM harness side
connector C-54 <A/T>.
(1) Disconnect the connector C-49, C-53 <M/T> or C-54 <A/T>

and measure at the harness side.

AK300419

1

14

4

19

5

22

6

17

8

15

9

18

7

20

16

2

21

23

26

24

25

3

10

11

12

13

34 33 32

36 35

37

42

45

31

39

38

46

40

41

43

44

CONNECTORS: C-49, C-53 <M/T>

C-53 (G)

C-49 (G)

AB

C-53 HARNESS CONNECTOR:
COMPONENT SIDE

C-49 HARNESS CONNECTOR:
COMPONENT SIDE

AK300412

42

43

48

49

50

51

52

53

54

55

56

57

46 45 44

58

59

60

61

62

63

64

65

66

47

41

C-54 (GR)

CONNECTOR: C-54 <A/T>

AB

HARNESS CONNECTOR:
COMPONENT SIDE

MULTIPORT FUEL INJECTION (MFI) DIAGNOSIS

TSB Revision

MULTIPORT FUEL INJECTION (MFI) <2.4L>

13A-852

(2) Using a jumper wire, connect terminal No. 38 <M/T> or No.

49 <A/T> to ground.

(3) Measure the voltage between terminal (No. 12, No. 25)

<M/T> or (No. 41, No. 47) <A/T> and ground.

• Voltage should be battery positive voltage.

Q: Is battery positive voltage (approximately 12 volts)

present?
YES : Replace the ECM or PCM. Then confirm that the

malfunction symptom is eliminated.

NO :  Repair harness wire between MFI relay connector

A-18X (terminal No. 4) and ECM connector C-49
(terminal No. 12, No. 25) <M/T> or PCM connector
C-54 (terminal No. 41, No. 47) <A/T> because of
open circuit. Then confirm that the malfunction
symptom is eliminated.

AK000407

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

31

32

33

34

35

36

37

38

39

40

41

42

43

44

45

46

<M/T>

HARNESS CONNECTOR:
COMPONENT SIDE

C-49

C-53

AH

AKX01438

<A/T>

C-54 HARNESS
CONNECTOR:
COMPONENT SIDE

41

42

43

44

45

46

47

48

49

50

51

52

53

54

55

56

57

58

59

60

61

62

63

64

65

66

AR
