Mitsubishi Colt Ralliart. Manual - part 577





DRIVER'S AND PASSENGER'S (FRONT) AIR BAG MODULES AND CLOCK SPRING

SUPPLEMENTAL RESTRAINT SYSTEM (SRS)

52B-146

<DRIVER’S AIR BAG MODULE AND CLOCK SPRING>

Pre-removal Operation
• Disconnect the Negative Battery Terminal.

AC208525

AC208935

AC207738

AC207739

AD

1

2

1

2

3

4

41 ± 8 N·m

2

Claw

3

9.0 ± 2.0 N·m

0.69 ± 0.15 N·m

N

Claw

Driver’s air bag module removal
steps

<<

A

>>

1. Cover

Horn connector connection

<<

B

>>

Driver’s air bag module connector
connection

<<

C

>>

2. Driver’s air bag module

<<

D

>>

3. Steering wheel

Clock spring removal steps

<<

A

>>

1. Cover

Horn connector connection

<<

B

>>

Driver’s air bag module connector
connection

<<

C

>>

2. Driver’s air bag module

<<

D

>>

3. Steering wheel

Column cover (Refer to GROUP 37,
Steering shaft

P.37-92

).

<<

E

>>

4. Clock spring

Driver’s air bag module installation
steps

>>

A

<< • Pre-installation inspection

>>

C

<< 3. Steering wheel

>>

C

<< 2. Driver’s air bag module

Driver’s air bag module connector
connection

Horn connector connection

>>

D

<< 1. Cover

Negative (

−) battery cable connection

>>

E

<< • Post-installation inspection

Clock spring installation steps

>>

A

<< • Pre-installation inspection

>>

B

<< 4. Clock spring

Column cover (Refer to GROUP 37,
Steering shaft

P.37-92

).

>>

C

<< 3. Steering wheel

>>

C

<< 2. Driver’s air bag module

Driver’s air bag module connector
connection

Horn connector connection

>>

D

<< 1. Cover

Negative (

−) battery cable connection

>>

E

<< • Post-installation inspection

Driver’s air bag module installation
steps (Continued)

Main

Index

Group

TOC

DRIVER'S AND PASSENGER'S (FRONT) AIR BAG MODULES AND CLOCK SPRING

SUPPLEMENTAL RESTRAINT SYSTEM (SRS)

52B-147

<PASSENGER'S (FRONT) AIR BAG MODULE>

Pre-removal Operation
• Turn the ignition switch the "LOCK" (OFF) position.
• Disconnect the Negative Battery Terminal.

AC208439

1

AC

Removal steps

Instrument panel assembly (Refer to
GROUP 52A, Instrument panel
assembly

P.52A-8

).

<<

F

>>

1. Passenger’s (front) air bag module

Installation steps

>>

A

<< • Pre-installation inspection

1. Passenger’s (front) air bag module

Instrument panel assembly (Refer to
GROUP 52A, Instrument panel
assembly

P.52A-8

).

Negative (

−) battery cable connection

>>

E

<< • Post-installation inspection

Installation steps (Continued)

Main

Index

Group

TOC

DRIVER'S AND PASSENGER'S (FRONT) AIR BAG MODULES AND CLOCK SPRING

SUPPLEMENTAL RESTRAINT SYSTEM (SRS)

52B-148

REMOVAL SERVICE POINTS
<<A>> COVER REMOVAL

1. Insert the special tool ornament remover

(MB990784) as shown in the illustration to remove
the cover.

2. Remove the horn connector secured to the cover.

<<B>> DRIVER’S AIR BAG MODULE
CONNECTOR DISCONNECTION

Disconnect the clock spring connector while com-
pressing its locking button and sliding it to the direc-
tion of an arrow.

<<C>> DRIVER’S AIR BAG MODULE
REMOVAL

WARNING

The air bag module must not be measured
with such equipment as an ohmmeter, nor
disassembled.

The removed air bag module should be
stored in a clean, dry place with the
deployment surface facing up.

1. Remove the driver’s air bag module mounting

screws (Torx screws) at the sides of the steering
wheel.
NOTE: Do not remove the screws from the hold-
ers.

<<D>> STEERING WHEEL REMOVAL

1. Position the steering wheel in the straight-ahead

position.

2. Use special tool steering wheel puller

(MB990803) to remove the steering wheel.

<<E>> CLOCK SPRING REMOVAL

WARNING

The removed clock spring should be stored
in a clean, dry place.

AC211761AB

MB990784

AC209070AE

Horn connector fixing point

Cover

AC302435

Locking

button

AI

Clock spring

connector

Steering wheel

connector

AC312338

Section A-A

Mounting screw

(Torx screw)

A

A

AB

AC000991

MB990803

AD

Main

Index

Group

TOC

DRIVER'S AND PASSENGER'S (FRONT) AIR BAG MODULES AND CLOCK SPRING

SUPPLEMENTAL RESTRAINT SYSTEM (SRS)

52B-149

<<F>> PASSENGER’S (FRONT) AIR BAG
MODULE REMOVAL

WARNING

When the passenger’s (front) air bag mod-
ule is removed, do not damage the
engagement of the pawls.

The removed passenger’s (front) air bag
module should be stored in a clean, dry
place with facing the deployment surface
facing up.

INSTALLATION SERVICE POINTS
>>A<< PRE-INSTALLATION INSPECTION

WARNING

Dispose of air bag modules only according
to the specified procedure (Refer to

P.52B-162

).

1. When installing the new air bag modules and

clock spring, refer to “INSPECTION” (

P.52B-151

).

2. Connect the negative (

−) battery cable.

CAUTION

To prevent damage to M.U.T.-III, always turn the
ignition, switch to the “LOCK” (OFF) position
before connecting or disconnecting M.U.T.-III.
3. Connect M.U.T.-III to the diagnosis connector.

4. Turn the ignition switch to the “ON” position.
5. Check diagnosis codes using M.U.T.-III to ensure

that the SRS operates properly.
At this time, check that no diagnosis code except
21 and 24 are set.

DANGER

Wait at least 60 seconds after disconnecting
the battery cable before doing any further
work (Refer to

P.52B-5

).

6. Turn the ignition switch to the "LOCK" (OFF)

position. Disconnect the negative (

−) battery cable

and tape the terminal to prevent accidental
connection and air bags deployment.

>>B<< CLOCK SPRING INSTALLATION

WARNING

Ensure that the clock spring’s mating marks
are properly aligned. If not, the steering
wheel may not rotate completely during a
turn, or the flat cable in the clock spring
could be damaged, This would prevent nor-
mal SRS operation and possibly cause seri-
ous injury to the driver.

1. Align the mating marks of the clock spring.

<Mating Mark Alignment>
Turn the clock spring clockwise fully. Then turn it
back approximately 3 3/4 turns anticlockwise to
align the mating marks.

2. Turn the front wheels to the straight-ahead

position. Then install the clock spring to the
column switch.

AC206895

AC

Diagnosis

connector

MB991827

MB991824

MB991910

AC300168

Mating marks

AB
