TROUBLESHOOTING ANTI-SKID BRAKING SYSTEM (ABS) 35B-24 (2) Resistance between ABS-ECU connector A-05 terminal 19 and rear right wheel speed sensor OK: 10 Ω or less (3) Resistance between ABS-ECU connector A-05 terminal 8 and rear right wheel speed sensor OK: 10 Ω or less Q: Is the check result normal? YES : Go to Step 6. NO : Repair the wiring harness between STEP 6. Check whether the diagnosis code is CAUTION Before connecting or disconnecting the position. (4) Turn the ignition switch to the "ON" position. position. (7) Disconnect M.U.T.-III. Q: Is code No.C1210 set? YES : Replace the hydraulic unit (integrated with ABS-ECU) (Refer to ). NO : The malfunction is intermittent. Refer to − How to Cope with Intermittent Malfunction . AC314119AH C-06 Harness MB991951 Check ABS-ECU A-05 Harness connector AC314119AI C-06 Harness MB991951 Check ABS-ECU A-05 Harness connector AC206895 AC Diagnosis connector MB991827 MB991824 MB991910 Main Index Group TOC |
