CENTRALIZED JUNCTION
CIRCUIT DIAGRAMS
90-9
24
Fusible link No.6 (in
fusible link box)
10
Red
A/C compressor, A/C compressor
relay, engine-CVT-ECU <CVT> and
engine-ECU <M/T>
25
Ignition switch (ACC)
15
Blue
Cigarette lighter
26
15
Blue
ETACS-ECU, rear wiper motor and
washer motor
27
Fusible link No.6 (in
fusible link box)
20
Yellow
Sunroof motor assembly
28
−
−
−
29
10
Red
−
30
15
Blue
−
31
Fusible link No.1 (in
fusible link box)
10
Red
ETACS-ECU and turn-signal lamp
32
Ignition switch (ACC)
10
Red
−
33
Fusible link No.6 (in
fusible link box)
15
Blue
Diagnosis connector, ETACS-ECU,
door lock actuator and door mirror
assembly
34
15
Blue
Fog lamp and fog lamp relay
35
Headlamp relay: LO
15
Blue
Headlamp (LO)
36
15
Blue
Headlamp (LO)
37
Ignition switch (IG1)
7.5
Brown
Engine-CVT-ECU <CVT>, SRS-ECU
and back-up lamp
38
7.5
Brown
Engine-CVT-ECU <CVT>,
engine-ECU <M/T> and fuel pump
relay
39
10
Red
Ignition coil and noise condenser
40
7.5
Brown
ABS-ECU <4A91>, ASC-ECU
<4G15>, column switch, combination
meter, EPS-ECU, ETACS-ECU,
SRS-ECU, G and yaw rate sensor
and steering wheel sensor
41
Ignition switch (IG2)
7.5
Brown
Blower relay, combination meter,
cooling fan control relay,
engine-CVT-ECU <CVT>,
engine-ECU <M/T>, outside/inside air
selection damper control motor and
rear window defogger relay
