FASTENER TIGHTENING SPECIFICATIONS
AUTOMATIC TRANSMISSION OVERHAUL
23B-8
FASTENER TIGHTENING SPECIFICATIONS
M1233023100697
Item
Specification
Transmission
Roll stopper bracket
70
± 10 N⋅m
Control cable support bracket
23
± 3 N⋅m
Eye bolt
24
± 3 N⋅m
Oil cooler feed tube
11
± 1 N⋅m
Input shaft speed sensor
11
± 1 N⋅m
Output shaft speed sensor
11
± 1 N⋅m
Manual control lever
22
± 3 N⋅m
Inhibitor switch
11
± 1 N⋅m
Sealing cap <Type with sealing cap>
5.0
± 1.0 N⋅m
Valve body cover
11
± 1 N⋅m
Manual control shaft detente
6.0
± 1.0 N⋅m
Valve body mounting bolt
11
± 1 N⋅m
Fluid temperature sensor
11
± 1 N⋅m
Torque converter housing
48
± 6 N⋅m
Oil pump
29
± 2 N⋅m
Rear cover
23
± 3 N⋅m
Transfer drive gear
34
± 2 N⋅m
Anchor plug
98
± 15 N⋅m
Components
Direct planetary carrier lock nut
170
± 10 N⋅m
Differential drive gear
135
± 5 N⋅m
Solenoid valve support
6.0
± 1.0 N⋅m
Valve body
11
± 1 N⋅m
Plate
6.0
± 1.0 N⋅m
SEALANTS
M1233000500412
Item
Specified sealant
Rear cover
MITSUBISHI genuine sealant Part No. MD974421 or equivalent
Torque converter housing
MITSUBISHI genuine sealant Part No. MD974421 or equivalent
Valve body cover
MITSUBISHI genuine sealant Part No. MD974421 or equivalent
FORM-IN-PLACE GASKET (FIPG)
This transmission has several areas where the form-
in-place gasket (FIPG) is used for sealing. To ensure
that the FIPG fully serves its purpose, it is necessary
to observe some precautions when applying it. Bead
size, continuity and location are of paramount impor-
tance.
Too thin a bead could cause leaks. Too thick a bead,
on the other hand, could be squeezed out of location,
causing blocking or narrowing of fluid passages. To
prevent leaks or blocking of passages, therefore, it is
absolutely necessary to apply the FIPG evenly with-
out a break, while observing the correct bead size.
FIPG hardens as it reacts with the moisture in the
atmospheric air, and it is usually used for sealing
metallic flange areas.
