CRANKSHAFT AND CYLINDER BLOCK ENGINE OVERHAUL <3.8L ENGINE> 11B-54 INSTALLATION SERVICE POINTS . >>B<< KNOCK SENSOR BRACKET Check that the bracket is in proper contact with the cylinder Tightening torque: 28 ± 2 N⋅m (21 ± 1 ft-lb) . >>C<< CRANKSHAFT BEARING INSTALLATION 1. Measure the crankshaft journal diameter and confirm its classification from the following table. In the case of a 2. The cylinder block bearing bore diameter identification marks are stamped at the position shown in the illustration AKX00649 TIMING BELT SIDE AB 1 2 3 4 AKX01391 No.4 JOURNAL No.1 JOURNAL No.2 JOURNAL No.3 JOURNAL LOCATION OF IDENTIFCATION COLOR AB AKX00648 BEARING BORE DIAMETER IDENTIFICATION MARK CYLINDER INSIDE DIAMETER SIZE MARK TIMING BELT SIDE AB No.4 No.2 No.3 No.1 CRANKSHAFT JOURNAL OUTSIDE CYLINDER BLOCK CRANKSHAFT CRANKSHAFT IDENTIFICATION SIZE mm (in) IDENTIFICATION IDENTIFICATION IDENTIFICATION Yellow 63.994 − 64.000 (2.5194 − 2.5197) I Pink Blue II Red Pink III Green Red None 63.988 − 63.994 (2.5192 − 2.5194) I Red Pink II Green Red III Black Green |
