TOWING AND HOISTING

GENERAL

00-26

TOWING AND HOISTING

M1001000800380

TOWING THE VEHICLE BY A TOW TRUCK

.

CAUTION

This vehicle cannot be towed by a tow truck using
sling-type equipment (TYPE A) as illustrated; otherwise it
will damage the bumper and front end. If this vehicle is
towed, use wheel lift or flat bed equipment.

• If the transmission is malfunctioning or damaged,

transport the vehicle with the driving wheels on a car-
riage (TYPE C, D or E) as illustrated.

• If you tow the vehicles with an A/T with the driving

wheels on the ground (TYPE B) as illustrated, make
sure that the towing speed and distance given below
are never exceeded, causing damage to the transmis-
sion.

• Towing speed:  50km/h
• Towing distance:  30km

• For the towing speed and the towing distance, follow

the local driving laws and regulations.

.

TOWING WITH FRONT WHEELS OFF THE
GROUND  (TYPE C)

The vehicle may be towed on its rear wheels for extended dis-
tances provided the parking brake is released and gearshift
lever is in the "Neutral" position (M/T) or the selector lever is in
the "N" (NEUTRAL) position (A/T). It is recommended that vehi-
cles be towed using the front pickup whenever possible.

CAUTION

[For vehicles equipped with the traction control system
(TCL)]

• If the vehicle is towed with the ignition key in the "ON"

position and only the front wheels or only the rear
wheels raised of the ground, a malfunction may occur
in the device

.

00DB093A

TOWING AND HOISTING

GENERAL

00-27

TOWING WITH REAR WHEELS OFF THE
GROUND  (TYPE B)

Place the gearshift lever in the "Neutral" position (M/T) or the
selector lever in the "N" (NEUTRAL) position (A/T). Turn the
ignition key to the "ACC" position and secure the steering
wheel in a straight-ahead position with a rope or tie-down strap.
Never place the ignition key in the "LOCK" position when tow-
ing.

CAUTION

• Never tow an A/T vehicle with the rear wheels up (and

the front wheels on the ground) when the automatic
transmission fluid level is low. this may cause serious
and expensive damage to the transmission.

• Do not use the steering column lock to secure the front

wheels for towing.

• Make sure the transaxle is in Neutral if vehicle will have

drive wheels on the ground.

• If these requirements cannot be met, the front wheels

must be placed on a tow dolly.

.

TOWING WHEN KEYS ARE NOT AVAILABLE

When a locked vehicle must be towed and keys are not avail-
able, the vehicle may be lifted and towed from the front, pro-
vided the parking brake is released. If not released, the rear
wheels should be placed on a tow dolly.

.

SAFETY PRECAUTIONS

The following precautions should be taken when towing the
vehicle:

1. DO NOT LIFT OR TOW THE VEHICLE BY ATTACHING

TO OR WRAPPING AROUND THE BUMPER.

2. Any loose, protruding, or damaged parts such as hoods,

doors, fenders, trim, etc. should be secured or removed
prior to moving the vehicle.

00DB093A

TOWING AND HOISTING

GENERAL

00-28

3. Refrain from going under a vehicle when it is lifted by the

towing equipment, unless the vehicle is adequately sup-
ported by safety stands.

4. Never allow passengers to ride in a towed vehicle.
5. State and local rules and regulations must be followed when

towing a vehicle.

LIFTING, JACKING SUPPORT LOCATION

.

FLOOR JACK

CAUTION

• Never place a support at any point other than the speci-

fied one, or that point will be deformed.

••For lifting, put rubber or similar material between the

side sill and rigid rack, otherwise the side sill area will
be damaged.

00DB096A

Side view

Under view

SILL

COVER

TOWING AND HOISTING

GENERAL

00-29

.

POST TYPE

Special care should be taken when raising the vehicle on a
frame contact type hoist. The hoist must be equipped with the
proper adapters in order to support the vehicle at the proper
locations.

AC307266AB

RUBBER

RIGID RACK

CENTER MEMBER

RIGID RACK

NOTCH

REAR SUSPENSION CROSSMEMBER

NOTCH

RUBBER
