SYMPTOM PROCEDURES SIMPLIFIED WIRING SYSTEM (SWS) 54B-241 TECHNICAL DESCRIPTION (COMMENT) If the windshield wipers do not stop at predetermined . TROUBLESHOOTING HINTS • Refer to circuit diagrams GROUP- • Refer to configuration diagrams GROUP- • The wiring harness or connectors may have loose, corroded, or damaged terminals, or termi- • The windshield wiper motor may be defective • The front-ECU may be defective DIAGNOSIS Required Special Tool: • MB991223: Harness Set STEP1. Check windshield wiper motor connector A-03 for Q: Is windshield wiper motor connector A-03 in good condition? to GROUP 00E, Harness Connector Inspection . Verify that the windshield wiper works normally. 16DB425A A-03 (B) CONNECTOR: A-03 |
