VEHICLE IDENTIFICATION

GENERAL

00-14

CHASSIS NUMBER

The chassis number is stamped inside the bulkhead
as shown in the illustration.

No. Item

Content

1

Development NA

GRANDIS

2

Engine type

4

2,378mL

3

Sort

W

Wagon

4

Body style

L

4-door station wagon

5

Transmission
type

N

5-speed manual
transmission

R

4-speed automatic
transmission

6

Trim level

U

7 seating

H

6 seating

NA 4 W L N U Y L 6

AC310053

1

2 3

4

5 6 7 8 9

AB

7

Specification
engine
feature

Y

MPI-SOHC-MIVEC

8

Steering
wheel
location

L

Left hand

R

Right hand

9

Destination

6

For Europe

No. Item

Content

AC312100AB

AC310082

J

M

B

L

NA

4

W

4

Z

000001

N

AB

1

2

3

4

5

6

7

8

9

10

11

No.

Item

Content

1

Fixed figure

J

Asia

2

Distribution channel

M

Japan

3

Destination

A

For Europe, right hand drive

B

For Europe, left hand drive

4

Body style

L

4-door station wagon

5

Transmission type

N

5-speed manual transmission

R

4-speed automatic transmission

6

Development order

NA

GRANDIS

7

Engine

4

4G69: 2,378 mL petrol engine

8

Soft

W

Station wagon

9

Model year

4

2004

10

Plant

Z

Okazaki Motor Vehicle Works

11

Serial number

000001 to 999999

VEHICLE IDENTIFICATION

GENERAL

00-15

VEHICLE NAME PLATE

The name plate is riveted to the front end upper bar
in the engine room.

VEHICLES IDENTIFICATION NUMBER
LOCATION <VEHICLES FOR ENGLAND>

The vehicle identification number (VIN) is located on
a plate attached to the left top side of the instrument
panel.

AC310081

AB

AC310082

J

M

B

L

NA

4

W

4

Z

000001

N

AB

1

2

3

4

5

6

7

8

9

10

11

No.

Item

Content

1

Fixed figure

J

Asia

2

Distribution channel

M

Japan

3

Destination

A

For Europe, right hand drive

B

For Europe, left hand drive

4

Body style

L

4-door station wagon

5

Transmission type

N

5-speed manual transmission

R

4-speed automatic transmission

6

Development order

NA

GRANDIS

7

Engine

4

4G69: 2,378 mL petrol engine

8

Soft

W

Station wagon

9

Model year

4

2004

10

Plant

Z

Okazaki Motor Vehicle Works

11

Serial number

000001 to 999999

AC312156AB

AC312177

J M A L N NA 4 W 4 Z  0 0 0 0 0 1

1

2

3 4 5 6

7 8 9 10

11

AB

GENERAL DATA AND SPECIFICATIONS

GENERAL

00-16

ENGINE MODEL STAMPING

The engine model is stamped on the cylinder block.
This engine model numbers is as shown as follow.

The engine serial number is stamped near the
engine model number.

GENERAL DATA AND SPECIFICATIONS

M1001000900592

No. Item

Content

1

Fixed figure

J

ASIA

2

Distribution
channel

M

JAPAN

3

Destination

A

Vehicles for right hand

4

Body style

L

4-door station wagon

5

Transmission
type

N

5-speed manual
transmission

R

4-speed automatic
transmission

6

Development
order

NA GRANDIS

7

Engine

4

4G69: 2,378 mL petrol
engine

8

Sort

W

Station wagon

9

Model year

4

2004

10

Plant

Z

Okazaki Motor Vehicle
Works

11

Serial number

000001 to 999999

Engine model

Engine displacement

4G69

2,378 mL

Engine serial number

AA0201 to YY9999

AC310083AB

AC311125

1

2

3

4

5

6

7

8 9

10

AB

GENERAL DATA AND SPECIFICATIONS

GENERAL

00-17

NOTE: *: Vehicles with high earth suspensions <LH drive vehicles>

Item

NA4W
LNUYL6/R6 LRUYL6/R6 LNHYL6/R6 LRHYL6/R6

Vehicle
dimensions
mm

Front track

1

1,550

1,550

1,550

1,550

Overall width

2

1,795

1,795

1,795

1,795

Front overhang

3

900

900

900

900

Wheelbase

4

2,830

2,830

2,830

2,830

Rear overhang

5

1,035

1,035

1,035

1,035

Overall length

6

4,765

4,765

4,765

4,765

Ground clearance

7

155
165*

155
165*

155
165*

155
165*

Overall height

Without
roof rails

8

1,655
1,665*

1,655
1,665*

1,655
1,665*

1,655
1,665*

With roof
rails

9

1,690
1,700*

1,690
1,700*

1,690
1,700*

1,690
1,700*

Rear track

10

1,555

1,555

1,555

1,555

Vehicle
weight kg

Kerb weight

1,645

1,655

1,625

1,635

Max. gross vehicle weight

2,250

2,250

2,250

2,250

Max. axle weight rating-front

1,100

1,100

1,100

1,100

Max. axle weight rating-rear

1,190

1,190

1,190

1,190

Seating  capacity

7

7

6

6

Engine

Model code

4G69

4G69

4G69

4G69

Total displacement mL

2,378

2,378

2,378

2,378

Maximum output kW(PS)/rpm

121(165)/6,0
00

121(165)/6,0
00

121(165)/6,0
00

121(165)/6,0
00

Maximum torque
N

⋅m(kg-m)/rpm

217(22.1)/4,
000

217(22.1)/4,0
00

217(22.1)/4,0
00

217(22.1)/4,0
00

Transmission Model code

F5M42

F4A4B

F5M42

F4A4B

Type

5-speed
manual

4-speed
automatic

5-speed
manual

4-speed
automatic

Fuel system

Fuel supply system

MPI

MPI

MPI

MPI

Performance Maximum speed km/h

200

190

200

190

Minimum
turning radius
m

With 16-inch
wheel

5.5

5.5

5.5

5.5

With 17-inch
wheel

5.8

5.8

5.8

5.8
