Mitsubishi Grandis. Manual - part 338





INSTRUMENT PANEL ASSEMBLY

INTERIOR

52A-8

DISASSEMBLY AND REASSEMBLY

M1521001900343

REMOVAL SERVICE POINT
<<A>> PASSENGER’S (FRONT) AIR BAG
MODULE REMOVAL

WARNING

Never use an electric tester to diagnose
the air bag module circuit. Never attempt
to disassemble the air bag module.

The removed front passenger's air bag
module should be stored in a clean, dry
place with the deployment surface facing
up.

AC311802

1

2

1

3

4

5

6

7

7

8

9

e

e

c

c

c

c

c

c

c

c

e

e

c

c

c

c

c

f

f

k

k

AC

Disassembly steps

1.

Side defroster duct B

2.

Defroster nozzle

3.

Distribution duct

4.

Backbone bracket

<<A>>

5.

Air bag module (passenger’s side)

6.

Upper side lid

7.

Side upper bracket

8.

Bracket

9.

Instrument panel

FLOOR CONSOLE ASSEMBLY

INTERIOR

52A-9

FLOOR CONSOLE ASSEMBLY

REMOVAL AND INSTALLATION

M1521002200347

AC312130

1

2

3

4

5

6

7

8

Section A - A

4

6

Clip

AB

NOTE

: Clip position

A

A

Removal steps

1.

Floor console box mat

2.

Coin holder <Vehicles without
heated seat>

3.

Seat heater switch <Vehicles with
heated seat>

4.

Floor console panel

5.

Floor console plug

6.

Floor console

7.

Cigar lighter <LH drive vehicles>

8.

Floor console bracket

Removal steps (Continued)

INTERIOR TRIM

INTERIOR

52A-10

INTERIOR TRIM

REMOVAL AND INSTALLATION

M1521001100400

AC302767AB

8

7

5

13

6

3

2

10

9

11

12

16

4

17

18

22

23

21

15

20

19

14

44 ± 10 N·m

44 ± 10 N·m

44 ± 10 N·m

44 ± 10 N·m

1

24

25

1.

Front scuff plate outer

2.

Front scuff plate inner

3.

Cowl side trim

4.

Scuff plate rear

5.

Front door opening trim

6.

Rear door opening trim

7.

Front pillar trim

8.

Cowl side trim upper

9.

Front seat belt lower anchor bolt

10. Centre pillar trim lower
11. Front seat belt shoulder anchor bolt
12. Centre pillar trim plug
13. Centre pillar trim upper

14. Rear end trim
15. Tailgate opening trim
16. Second seat belt lower anchor bolt
17. Quarter trim plug
18. Quarter trim rear lid
19. Quarter side cover
20. Quarter trim lower
21. Third seat belt shoulder anchor bolt
22. Quarter trim cap
23. Quarter trim upper
24. Rear floor secret box
25. Luggage floor box

INTERIOR TRIM

INTERIOR

52A-11

CLIP AND CLAW POSITION

AC303429AB

B

B

A

A

C C

D

D

E

E

F

F

G

G

H

H

I

I

J

J

K

K

L

L

M

M

Clip

Clip

Clip

Clip

Clip

Clip

Clip

Clip

Clip

Clip

Clip

Claw

Claw

Cowl side
trim upper

Front
pillar trim

Cowl side trim

Front scuff
plate inner

Centre pillar  trim upper

Centre pillar  trim upper

Centre pillar  trim lower

Centre pillar  trim lower

Scuff plate rear

Quarter trim upper

Quarter trim lower

Rear end trim

Front scuff
plate outer

Claw

Claw

NOTE
(1)          : Clip position
(2)          : Claw position

Section A – A

Section B – B

Section C – C

Section D – D

Section E – E

Section F – F

Section G – G

Section H – H

Section I – I

Section J – J

Section K – K

Section L – L

Section M – M
