TROUBLESHOOTING SUPPLEMENTAL RESTRAINT SYSTEM (SRS) 52B-72 YES : Go to Step 5. NO : Repair the harness wires between STEP 5. Check whether the diagnosis code is Q: Is diagnosis code B1422 set? YES : Replace the SRS-ECU (Refer to NO : An intermittent malfunction is suspected ). Code No.B1423: Side-Airbag Module (RH) (Squib) System Fault Power Supply Circuit (Short-Circuited CAUTION If diagnosis code B1423 is set in the combination OPERATION • The SRS-ECU judges how severe a collision is by detecting signals from the left and right side • The ignition signal is input to the side-airbag module to inflate the side-airbag. DIAGNOSIS CODE SET CONDITIONS This diagnosis code is set if there is abnormal PROBABLE CAUSES • Damaged wiring harnesses or connectors • Short to the power supply in the side-airbag module (RH) (squib) harness • Malfunction of the SRS-ECU Wire colour code SIDE AIR BAG SRS-ECU CONNECTOR CONNECTOR : CONNECTOR NOTE Side-Airbag Module (RH) (Squib) Circuit |
