Mitsubishi L200. Manual - part 918

TAIL LAMP, POSITION LAMP, LICENCE PLATE LAMP AND LIGHTING MONITOR BUZZER

CIRCUIT DIAGRAMS

90-57

TAIL LAMP, POSITION LAMP, LICENCE PLATE LAMP AND LIGHTING MONITOR BUZZER <VEHICLES
WITH REAR BODY (LHD)> (CONTINUED)

DIAGNOSIS
CONNECTOR

FRONT
SIDE

ETACS-ECU

FUSE

12

J/B SIDE

VEHICLE
SPEED
SENSOR

ENGINE
CONTROL
RELAY

·CRUISE CONTROL
 SYSTEM
·ENGINE CONTROL
 SYSTEM
·GLOW SYSTEM
·IMMOBILIZER SYSTEM

ENGINE-ECU

ELC-4A/T

<VEHICLES WITH AUTO LAMP>

TAIL LAMP, POSITION LAMP, LICENCE PLATE LAMP AND LIGHTING MONITOR BUZZER

CIRCUIT DIAGRAMS

90-58

TAIL LAMP, POSITION LAMP, LICENCE PLATE LAMP AND LIGHTING MONITOR BUZZER <VEHICLES
WITH REAR BODY (LHD)> (CONTINUED)

ETACS-ECU

BUZZER

<VEHICLES WITH AUTO LAMP>

ETACS-ECU

LIGHTING
CONTROL
SENSOR

FUSE

13

DOOR
SWITCH
(FRONT: LH)

·CENTRAL DOOR
 LOCKING SYSTEM
 <VEHICLES WITH
 KEYLESS ENTRY SYSTEM>
·ROOM LAMP AND
 IGNITION KEY CYLINDER
 ILLUMINATION LAMP

ILLUMINATION
CONTROL
CIRCUIT

·CLOCK
·MMCS
·RADIO AND
 CD PLAYER
·RV METER
·SPARE CONNECTOR
 (FOR AUDIO)

Wire colour code
B : Black     LG : Light green     G : Green     L : Blue     W : White
Y : Yellow     SB : Sky blue     BR : Brown     O : Orange     GR : Grey
R : Red     P : Pink     V : Violet     PU : Purple     SI : Silver

TAIL LAMP, POSITION LAMP, LICENCE PLATE LAMP AND LIGHTING MONITOR BUZZER

CIRCUIT DIAGRAMS

90-59

TAIL LAMP, POSITION LAMP, LICENCE
PLATE LAMP AND LIGHTING MONITOR
BUZZER <VEHICLES WITH REAR BODY
(RHD)>

M1901001703571

20

FUSIBLE
LINK

(FUSE     )

15

IGNITION
SWITCH (IG1)

IGNITION
SWITCH (IG2)

LIN
INTERFACE

POWER
SOURCE

POWER
WINDOWS

J/B SIDE

POSITION
LAMP

(LH)

(RH)

REAR
COMBINATION
LAMP

(TAIL: RH) (TAIL: LH)

LICENCE
PLATE LAMP

(RH)

(LH)

ETACS-ECU

TAIL LAMP
RELAY

Wire colour code
B : Black     LG : Light green     G : Green     L : Blue     W : White     Y : Yellow     SB : Sky blue
BR : Brown     O : Orange     GR : Grey     R : Red     P : Pink     V : Violet     PU : Purple     SI : Silver

COLUMN
SWITCH

COLUMN-ECU

LIGHTING
SWITCH

DIMMER·PASSING
SWITCH

(HEAD)

(TAIL)

(DIMMER)

(PASSING)

(AUTO)

VEHICLES WITH AUTO LAMP

:

NOTE

3

FUSIBLE
LINK

TAIL LAMP, POSITION LAMP, LICENCE PLATE LAMP AND LIGHTING MONITOR BUZZER

CIRCUIT DIAGRAMS

90-60

TAIL LAMP, POSITION LAMP, LICENCE PLATE LAMP AND LIGHTING MONITOR BUZZER <VEHICLES
WITH REAR BODY (RHD)> (CONTINUED)

DIAGNOSIS
CONNECTOR

FRONT
SIDE

ETACS-ECU

FUSE

12

J/B SIDE

VEHICLE
SPEED
SENSOR

ENGINE
CONTROL
RELAY

·CRUISE CONTROL
 SYSTEM
·ENGINE CONTROL
 SYSTEM
·GLOW SYSTEM
·IMMOBILIZER SYSTEM

ENGINE-ECU

ELC-4A/T

<VEHICLES WITH AUTO LAMP>
