Mitsubishi L200. Manual - part 715





COLUMN SWITCH

CHASSIS ELECTRICAL

54A-227

COLUMN SWITCH (SWITCH BODY)
CONTINUITY CHECK

M1543101000033

1. Remove the lighting switch, wiper and washer

switch.

2. Check that there is continuity of each same termi-

nal number (from Nos. 2 to 11) between each
connectors of column switch body left in the
steering column.

Switch position

Tester
connection

Specified
condition

OFF

Open circuit

Windshield intermittent
wiper interval adjusting
knob

− 3

Operating
the
adjusting
knob
changes the
resistance.

Windshield washer
switch

− 7

Continuity
exists (2

Ω

or less)

Windshield
wiper switch

Hi

− 8

Continuity
exists (2

Ω

or less)

Lo

− 9

Continuity
exists (2

Ω

or less)

Int

− 10

Continuity
exists (2

Ω

or less)

Mist

− 11

Continuity
exists (2

Ω

or less)

Column switch
body

Tester
connection

Specified
condition

• Lighting switch

side connector

• Wiper and

washer switch
side connector

− 2

− 3

− 4

− 5

− 6

− 7

− 8

− 9

10

− 10

11

− 11

Continuity
exists (2

Ω or

less)

AC502901

1

6

8

11

10

9

7

5

4

3

2

At wiper/washer
switch side

1

6

8

11

10

9

7

5

4

3

2

At lighting
switch side

AF

CLOCK

CHASSIS ELECTRICAL

54A-228

CLOCK

REMOVAL AND INSTALLATION

M1542700300029

RADIO AND CD PLAYER

GENERAL

M1544000101520

Two types of 1 DIN size radio and CD player have
been established.

AC502936AB

3

2

4

1

Removal steps

1.

Clock garnish

2.

Clock hole cover

3.

Digital clock

Headlining (Refer to GROUP 52A,
Headlining ).

4.

Clock bracket

Removal steps (Continued)

Item

Type 1

Type 2

Radio

AM/FM electronic tuning radio

Lw/MW/FM electronic tuning radio

Compatible
with RDS
function

Equipped

Player

CD player (Compatible with MP3)

CD player (Compatible with MP3)

Power amplifier
with radio

35W

× 4

35W

× 4

RADIO AND CD PLAYER

CHASSIS ELECTRICAL

54A-229

CONSTRUCTION DIAGRAM

EXTERNAL CONNECTION JACK (AUDIO ADAPTER)

The external connection jack (audio adapter) has
been installed on rear floor console. Therefore, port-
able music player and so on can be connected.
<Option: vehicles with radio and CD player>

SPECIAL TOOLS

M1542000602782

ACB01704 AB

<Type 1>

<Type 2>

AC809012

AB

Audio adopter

Rear floor console

Tool

Number

Name

Application

MB990784

Ornament remover

Removal of selector
panel, instrument centre
panel

MB990784

RADIO AND CD PLAYER

CHASSIS ELECTRICAL

54A-230

TROUBLESHOOTING

INTRODUCTION TO AUDIO SYSTEM
DIAGNOSIS

M1544018900346

The diagnosis for symptoms such as noise being
emitted, no sound being played, or sound coming
only out of one speaker (or set of speakers) is pro-
vided.

AUDIO ERROR CODES

If the radio and CD player, the iPod or the USB mem-
ory device which is connected to the USB box
detects any malfunction in itself or the inserted CD,
the error codes below will be shown on the RV meter.

RADIO AND CD PLAYER-RELATED ERROR CODE

MB991223

a. MB991219
b. MB991220
c. MB991221
d. MB991222

Harness set

a. Check harness
b. LED harness
c. LED harness

adapter

d. Probe

Continuity check and
voltage measurement at
harness wire or
connector

a. For checking

connector pin contact
pressure

b. For checking power

supply circuit

c. For checking power

supply circuit

d. For connecting a

locally sourced tester

MB992006

Extra fine probe

Continuity check and
voltage measurement at
harness wire or
connector

MB992279

Audio remover and
installer

Removal and install of
radio and CD player

Tool

Number

Name

Application

MB991223

a

d

c

b

DO NOT USE

BA

MB992006

MB992279

Error code

Cause

Cause of trouble and its solution

NO DISC

NO disc inserted

Insert disc.

ERROR 001

Focus error

If there is any problem on the CD, this error code will be shown. If
no error message appears when another disc is inserted, the
disc is defective. Check the items below, and take a necessary
action.

• Contamination, scratch, or deformation

• Formation of moisture or grease

Insert the disc again, and check that no error appears.

ERROR 002

Abnormal disc
